SUN HYDRAULICS
CXDCXAV
$41.80 USD
- SUN HYDRAULICS
- Material:CXDCXAV
- Model:CXDC-XAV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXDCXAV (CXDCXAV) is a versatile hydraulic check valve designed for high-performance applications requiring minimal leakage. This valve operates as a standard 2-port check valve within a 3-port cavity, with the third port effectively blocked, making it ideal for circuits that already have an existing three-port cavity. The CXDCXAV model features Sun Hydraulics\u2019 floating style construction, which significantly reduces the risk of internal parts binding due to over-torquing or variations in cavity or cartridge machining. With a capacity of up to 20 gpm (80 L/min) and a maximum operating pressure of 5000 psi (350 bar), this valve is engineered to handle substantial flow rates and pressure conditions efficiently. It offers exceptional sealing capabilities, evidenced by its extremely low maximum leakage rate of less than one drop per minute (0.07 cc/min), ensuring system integrity and performance are maintained. The valve's T11A cavity and Series 1 specification further highlight its compatibility and ease of integration into various hydraulic systems. For installation, the valve requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 \u2013 35 lbf\u00b7ft (41 \u2013 47 Nm). Additionally, it supports Viton seal kits for enhanced durability and chemical resistance under harsh conditions. Overall, the Sun Hydraulics CXDCXAV check valve is an effective solution for applications demanding reliable non-return functionality in hydraulic systems, particularly where space or existing configurations impose constraints.
The Sun Hydraulics CXDCXAV (CXDCXAV) is a versatile hydraulic check valve designed for high-performance applications requiring minimal leakage. This valve operates as a standard 2-port check valve within a 3-port cavity, with the third port effectively blocked, making it ideal for circuits that already have an existing three-port cavity. The CXDCXAV model features Sun Hydraulics\u2019 floating style construction, which significantly reduces the risk of internal parts binding due to over-torquing or variations in cavity or cartridge machining. With a capacity of up to 20 gpm (80 L/min) and a maximum operating pressure of 5000 psi (350 bar), this valve is engineered to handle substantial flow rates and pressure conditions efficiently. It offers exceptional sealing capabilities, evidenced by its extremely low maximum leakage rate of less than one drop per minute (0.07 cc/min), ensuring system integrity and performance are maintained. The valve's T11A cavity and Series 1 specification further highlight its compatibility and ease of integration into various hydraulic systems. For installation, the valve requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 \u2013 35 lbf\u00b7ft (41 \u2013 47 Nm). Additionally, it supports Viton seal kits for enhanced durability and chemical resistance under harsh conditions. Overall, the Sun Hydraulics CXDCXAV check valve is an effective solution for applications demanding reliable non-return functionality in hydraulic systems, particularly where space or existing configurations impose constraints.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 20 gpm80 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge | Viton: 990-011-006 |
