SUN HYDRAULICS
CXDCXEN
$30.88 USD
- SUN HYDRAULICS
- Material:CXDCXEN
- Model:CXDC-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXDCXEN (CXDCXEN) is a highly versatile and efficient hydraulic check valve designed for specialized applications. This model incorporates a unique free-flow, nose-to-side cheater check valve functionality within a standard 2-port check valve architecture, adapted for use in a 3-port cavity with the third port blocked off. This design allows for its integration into circuits that originally contain three-port cavities but only require the functionality of a two-port check valve, optimizing both space and functionality without the need for additional modifications. The CXDCXEN features Sun Hydraulics' floating style construction, which significantly reduces the risks associated with internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This construction enhances the valve\u2019s reliability and durability in demanding operational conditions. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity up to 20 gpm (80 L/min), this valve is engineered to handle substantial hydraulic loads while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min), ensuring high efficiency in fluid control. This model is housed in a T11A series cavity, requiring an installation torque between 30 - 35 lbf.ft (41 - 47 Nm) and utilizes Viton seals for enhanced performance under varying environmental conditions. The compact hex size of 7/8 in. (22.2 mm) facilitates easy installation and maintenance, making the CXDCXEN an ideal solution for enhancing hydraulic system reliability where space and precise flow control are critical.
The Sun Hydraulics CXDCXEN (CXDCXEN) is a highly versatile and efficient hydraulic check valve designed for specialized applications. This model incorporates a unique free-flow, nose-to-side cheater check valve functionality within a standard 2-port check valve architecture, adapted for use in a 3-port cavity with the third port blocked off. This design allows for its integration into circuits that originally contain three-port cavities but only require the functionality of a two-port check valve, optimizing both space and functionality without the need for additional modifications. The CXDCXEN features Sun Hydraulics' floating style construction, which significantly reduces the risks associated with internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This construction enhances the valve\u2019s reliability and durability in demanding operational conditions. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity up to 20 gpm (80 L/min), this valve is engineered to handle substantial hydraulic loads while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min), ensuring high efficiency in fluid control. This model is housed in a T11A series cavity, requiring an installation torque between 30 - 35 lbf.ft (41 - 47 Nm) and utilizes Viton seals for enhanced performance under varying environmental conditions. The compact hex size of 7/8 in. (22.2 mm) facilitates easy installation and maintenance, making the CXDCXEN an ideal solution for enhancing hydraulic system reliability where space and precise flow control are critical.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 20 gpm80 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge | Viton: 990-011-006 |
