SUN HYDRAULICS
CXDCXEV
$38.82 USD
- SUN HYDRAULICS
- Material:CXDCXEV
- Model:CXDC-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXDCXEV (CXDCXEV) is a specialized hydraulic check valve designed for versatility and efficiency in fluid power applications. This model is part of the T11A cavity series and is engineered to function as a standard 2-port check valve when used in a 3-port cavity with port 3 blocked off. Such configuration flexibility makes it particularly useful for adapting existing systems without the need for extensive modifications. The CXDCXEV valve supports a maximum flow capacity of 20 gpm (80 L/min) and can withstand operating pressures up to 5000 psi (350 bar). It features an exceptionally low leakage rate, with a maximum of less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and increased efficiency in system operations. The valve incorporates Sun\u2019s floating style construction which reduces the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. With a hex size of 7/8 in. (22.2 mm) and an installation torque range of 30-35 lbf\u00b7ft (41-47 Nm), this valve is designed for easy installation while maintaining robust performance under demanding conditions. The use of Viton seals ensures compatibility with a wide range of fluids and enhances the durability against high temperatures and chemical degradation, making the CXDCXEV an ideal choice for various hydraulic applications requiring reliable, non-return functionality.
The Sun Hydraulics CXDCXEV (CXDCXEV) is a specialized hydraulic check valve designed for versatility and efficiency in fluid power applications. This model is part of the T11A cavity series and is engineered to function as a standard 2-port check valve when used in a 3-port cavity with port 3 blocked off. Such configuration flexibility makes it particularly useful for adapting existing systems without the need for extensive modifications. The CXDCXEV valve supports a maximum flow capacity of 20 gpm (80 L/min) and can withstand operating pressures up to 5000 psi (350 bar). It features an exceptionally low leakage rate, with a maximum of less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and increased efficiency in system operations. The valve incorporates Sun\u2019s floating style construction which reduces the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. With a hex size of 7/8 in. (22.2 mm) and an installation torque range of 30-35 lbf\u00b7ft (41-47 Nm), this valve is designed for easy installation while maintaining robust performance under demanding conditions. The use of Viton seals ensures compatibility with a wide range of fluids and enhances the durability against high temperatures and chemical degradation, making the CXDCXEV an ideal choice for various hydraulic applications requiring reliable, non-return functionality.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 20 gpm80 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge | Viton: 990-011-006 |
