SUN HYDRAULICS
CXDCXZN
$34.85 USD
- SUN HYDRAULICS
- Material:CXDCXZN
- Model:CXDC-XZN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXDCXZN (CXDCXZN) is a versatile check valve designed for hydraulic systems requiring reliable, low-leakage one-way flow control in a three-port cavity setup. This model stands out due to its innovative design that allows it to function as a standard two-port check valve while blocking off port 3, making it ideal for applications where space or existing port configurations are constraints. The CXDCXZN features Sun Hydraulics' floating style construction which significantly reduces the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. With a capacity of 20 gpm (80 L/min) and a maximum operating pressure of 5000 psi (350 bar), this check valve is engineered to handle demanding conditions while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min). Its robust construction includes a valve hex size of 7/8 in. (22.2 mm) and an installation torque range of 30 \u2013 35 lbf ft (41 \u2013 47 Nm), ensuring a secure fit and optimal performance in various hydraulic setups. The CXDCXZN uses Viton seals for enhanced temperature and chemical resistance, further underpinning its suitability for tough industrial applications. This model is housed within the T11A cavity and belongs to the Series 1 line-up from Sun Hydraulics, known for their reliability and efficiency in fluid power applications. Whether used in mobile hydraulics, industrial machinery, or other systems requiring precise flow control, the CXDCXZN provides a high-performance solution that engineers and technicians can rely on for effective and efficient operation.
The Sun Hydraulics CXDCXZN (CXDCXZN) is a versatile check valve designed for hydraulic systems requiring reliable, low-leakage one-way flow control in a three-port cavity setup. This model stands out due to its innovative design that allows it to function as a standard two-port check valve while blocking off port 3, making it ideal for applications where space or existing port configurations are constraints. The CXDCXZN features Sun Hydraulics' floating style construction which significantly reduces the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. With a capacity of 20 gpm (80 L/min) and a maximum operating pressure of 5000 psi (350 bar), this check valve is engineered to handle demanding conditions while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min). Its robust construction includes a valve hex size of 7/8 in. (22.2 mm) and an installation torque range of 30 \u2013 35 lbf ft (41 \u2013 47 Nm), ensuring a secure fit and optimal performance in various hydraulic setups. The CXDCXZN uses Viton seals for enhanced temperature and chemical resistance, further underpinning its suitability for tough industrial applications. This model is housed within the T11A cavity and belongs to the Series 1 line-up from Sun Hydraulics, known for their reliability and efficiency in fluid power applications. Whether used in mobile hydraulics, industrial machinery, or other systems requiring precise flow control, the CXDCXZN provides a high-performance solution that engineers and technicians can rely on for effective and efficient operation.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 20 gpm80 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge | Viton: 990-011-006 |
