SUN HYDRAULICS
CXEBXBN
$87.17 USD
- SUN HYDRAULICS
- Material:CXEBXBN
- Model:CXEB-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEBXBN (CXEBXBN) is a robust two-port check valve designed for on-off circuit applications, facilitating free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction. This model is particularly suited for medium pressure systems that handle dirty environments but are not exposed to high flows or extreme temperatures. The Delrin seat enhances its suitability for such conditions, ensuring durability and reliability. The CXEBXBN features a maximum capacity of 30 gpm (120 L/min) and can withstand a maximum operating pressure of up to 3000 psi (210 bar). It is engineered with Sun's floating style construction which minimizes the risk of internal parts binding\u2014a common issue due to excessive installation torque or variations in cavity/cartridge machining. This design detail underscores its utility in circuit correction applications, especially where manifold drillings may be incorrect. Furthermore, this model boasts an extremely low leakage rate with less than one drop per minute (0.07 cc/min), making it an efficient choice for systems requiring stringent fluid control. The valve\u2019s hex size is 1 1/8 in (28.6 mm), and it requires an installation torque of between 45 - 50 lbf\u00b7ft (61 - 68 Nm). Weighing just .40 lb (0.20 kg), the CXEBXBN combines lightweight design with high performance and reliability, embodied in its compact yet powerful framework. This valve uses Viton seals for enhanced chemical resistance and durability under various operating conditions.
The Sun Hydraulics CXEBXBN (CXEBXBN) is a robust two-port check valve designed for on-off circuit applications, facilitating free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction. This model is particularly suited for medium pressure systems that handle dirty environments but are not exposed to high flows or extreme temperatures. The Delrin seat enhances its suitability for such conditions, ensuring durability and reliability. The CXEBXBN features a maximum capacity of 30 gpm (120 L/min) and can withstand a maximum operating pressure of up to 3000 psi (210 bar). It is engineered with Sun's floating style construction which minimizes the risk of internal parts binding\u2014a common issue due to excessive installation torque or variations in cavity/cartridge machining. This design detail underscores its utility in circuit correction applications, especially where manifold drillings may be incorrect. Furthermore, this model boasts an extremely low leakage rate with less than one drop per minute (0.07 cc/min), making it an efficient choice for systems requiring stringent fluid control. The valve\u2019s hex size is 1 1/8 in (28.6 mm), and it requires an installation torque of between 45 - 50 lbf\u00b7ft (61 - 68 Nm). Weighing just .40 lb (0.20 kg), the CXEBXBN combines lightweight design with high performance and reliability, embodied in its compact yet powerful framework. This valve uses Viton seals for enhanced chemical resistance and durability under various operating conditions.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
