SUN HYDRAULICS
CXEBXCN
$85.18 USD
- SUN HYDRAULICS
- Material:CXEBXCN
- Model:CXEB-XCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEBXCN (CXEBXCN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. Ideal for medium pressure applications, this valve permits free flow from its inlet port 2 to the outlet port 1 while preventing backflow in the reverse direction. The CXEBXCN features a Delrin seat, which enhances its durability and suitability in environments with dirty fluids, although it is not recommended for high flow or high-temperature conditions. This model operates within a maximum pressure limit of 3000 psi (210 bar) and supports a flow capacity up to 30 gpm (120 L/min), making it versatile for various hydraulic circuit applications. The valve ensures minimal leakage, with a maximum rate of less than one drop per minute (0.07 cc/min), thus maintaining system integrity and reducing fluid loss. Incorporating Sun Hydraulics' floating style construction, the CXEBXCN minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This feature helps maintain operational consistency and long-term reliability of the valve. The product's compact design includes a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf.ft (61 - 68 Nm). Weighing only 0.40 lb (0.20 kg), it offers an efficient solution without adding significant weight to the system setup. Overall, the Sun Hydraulics CXEBXCN check valve is particularly useful as a circuit saver in systems where manifold drillings might be incorrectly configured, providing an effective means to correct these issues without extensive modifications.
The Sun Hydraulics CXEBXCN (CXEBXCN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. Ideal for medium pressure applications, this valve permits free flow from its inlet port 2 to the outlet port 1 while preventing backflow in the reverse direction. The CXEBXCN features a Delrin seat, which enhances its durability and suitability in environments with dirty fluids, although it is not recommended for high flow or high-temperature conditions. This model operates within a maximum pressure limit of 3000 psi (210 bar) and supports a flow capacity up to 30 gpm (120 L/min), making it versatile for various hydraulic circuit applications. The valve ensures minimal leakage, with a maximum rate of less than one drop per minute (0.07 cc/min), thus maintaining system integrity and reducing fluid loss. Incorporating Sun Hydraulics' floating style construction, the CXEBXCN minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This feature helps maintain operational consistency and long-term reliability of the valve. The product's compact design includes a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf.ft (61 - 68 Nm). Weighing only 0.40 lb (0.20 kg), it offers an efficient solution without adding significant weight to the system setup. Overall, the Sun Hydraulics CXEBXCN check valve is particularly useful as a circuit saver in systems where manifold drillings might be incorrectly configured, providing an effective means to correct these issues without extensive modifications.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
