SUN HYDRAULICS
CXEBXEN
$85.18 USD
- SUN HYDRAULICS
- Material:CXEBXEN
- Model:CXEB-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEBXEN (CXEBXEN) is a highly efficient check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a free flow from the inlet port 2 to the outlet port 1 while blocking flow in the reverse direction, making it ideal for applications where preventing backflow is critical. The CXEBXEN utilizes a Delrin seat, which is particularly suited for medium pressure systems that encounter dirty conditions but do not experience high flows or temperatures. This check valve operates under a maximum pressure of 3000 psi (210 bar) and supports a flow capacity of up to 30 gpm (120 L/min), ensuring adequate performance for various hydraulic needs. The model is built with Sun\u2019s floating style construction, which minimizes risks associated with internal parts binding due to installation torque or variations in cavity/cartridge machining. This design feature enhances the durability and reliability of the valve. Additionally, the CXEBXEN boasts an impressively low leakage rate, with maximum leakage less than 1 drop per minute (0.07 cc/min), which is crucial for maintaining system efficiency and preventing fluid loss. The valve's dimensions include a hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm), making it compatible with various setups without requiring extensive modifications. Weighing only 0.40 lb (0.20 kg), this model offers a lightweight yet robust solution for enhancing hydraulic circuit functionality.
The Sun Hydraulics CXEBXEN (CXEBXEN) is a highly efficient check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a free flow from the inlet port 2 to the outlet port 1 while blocking flow in the reverse direction, making it ideal for applications where preventing backflow is critical. The CXEBXEN utilizes a Delrin seat, which is particularly suited for medium pressure systems that encounter dirty conditions but do not experience high flows or temperatures. This check valve operates under a maximum pressure of 3000 psi (210 bar) and supports a flow capacity of up to 30 gpm (120 L/min), ensuring adequate performance for various hydraulic needs. The model is built with Sun\u2019s floating style construction, which minimizes risks associated with internal parts binding due to installation torque or variations in cavity/cartridge machining. This design feature enhances the durability and reliability of the valve. Additionally, the CXEBXEN boasts an impressively low leakage rate, with maximum leakage less than 1 drop per minute (0.07 cc/min), which is crucial for maintaining system efficiency and preventing fluid loss. The valve's dimensions include a hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm), making it compatible with various setups without requiring extensive modifications. Weighing only 0.40 lb (0.20 kg), this model offers a lightweight yet robust solution for enhancing hydraulic circuit functionality.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
