SUN HYDRAULICS
CXEBXEV
$91.64 USD
- SUN HYDRAULICS
- Material:CXEBXEV
- Model:CXEB-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEBXEV (CXEBXEV) is a high-performance check valve designed for hydraulic systems requiring reliable, directional flow control. This model, featuring a Delrin seat, is particularly suited for medium pressure systems that encounter dirty conditions but do not involve high flow rates or extreme temperatures. Unique to this model is its sidetonose check valve configuration which allows free flow from port 2 to port 1 while blocking the reverse flow, making it an essential component for circuit correction in existing systems with incorrect manifold drillings. The CXEBXEV operates optimally within a hydraulic capacity of up to 30 gallons per minute (120 liters per minute) and can withstand a maximum operating pressure of 3000 psi (210 bar). It stands out for its extremely low leakage rate, maintaining less than one drop per minute (0.07 cc/min), which ensures minimal loss and efficient operation. The check valve incorporates Sun\u2019s floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model requires an installation torque between 45 - 50 lbf.ft (61 - 68 Nm) and has a compact hex size of 1 1/8 inches (28.6 mm), making it versatile for various setups. Weighing only 0.40 lbs (0.20 kg), the CXEBXEV is lightweight yet robust enough to handle demanding applications. Additionally, it uses Viton seals for enhanced durability and chemical resistance, ensuring long service life and reliability in challenging environments.
The Sun Hydraulics CXEBXEV (CXEBXEV) is a high-performance check valve designed for hydraulic systems requiring reliable, directional flow control. This model, featuring a Delrin seat, is particularly suited for medium pressure systems that encounter dirty conditions but do not involve high flow rates or extreme temperatures. Unique to this model is its sidetonose check valve configuration which allows free flow from port 2 to port 1 while blocking the reverse flow, making it an essential component for circuit correction in existing systems with incorrect manifold drillings. The CXEBXEV operates optimally within a hydraulic capacity of up to 30 gallons per minute (120 liters per minute) and can withstand a maximum operating pressure of 3000 psi (210 bar). It stands out for its extremely low leakage rate, maintaining less than one drop per minute (0.07 cc/min), which ensures minimal loss and efficient operation. The check valve incorporates Sun\u2019s floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model requires an installation torque between 45 - 50 lbf.ft (61 - 68 Nm) and has a compact hex size of 1 1/8 inches (28.6 mm), making it versatile for various setups. Weighing only 0.40 lbs (0.20 kg), the CXEBXEV is lightweight yet robust enough to handle demanding applications. Additionally, it uses Viton seals for enhanced durability and chemical resistance, ensuring long service life and reliability in challenging environments.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
