SUN HYDRAULICS
CXEBXFV
$93.62 USD
- SUN HYDRAULICS
- Material:CXEBXFV
- Model:CXEB-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEBXFV (CXEBXFV) is a precision-engineered check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a free flow from its inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction. It stands out for its low leakage rate, which is less than one drop per minute (0.07 cc/min), making it ideal for applications where minimal fluid loss is critical. Constructed with a Delrin seat, the CXEBXFV is particularly suited for medium-pressure systems that may contain some level of contamination. It can handle up to 30 gallons per minute (120 L/min) and withstand pressures up to 3000 psi (210 bar). The valve's design incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model uses a T5A cavity and belongs to the Series 2 lineup from Sun Hydraulics. The valve has an installation torque requirement of 45-50 lbf ft (61-68 Nm) and weighs approximately 0.40 lb (0.20 kg). Its hex size measures at 1-1/8 inches (28.6 mm), ensuring compatibility with standard tools for installation and maintenance. The CXEBXFV is particularly beneficial in circuits where manifold drillings are incorrect, serving as a circuit saver by adapting to existing configurations without the need for extensive modifications. Additionally, it offers compatibility with Viton seal kits under part number 990203006, providing further customization and maintenance options tailored to specific operational requirements and environments.
The Sun Hydraulics CXEBXFV (CXEBXFV) is a precision-engineered check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a free flow from its inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction. It stands out for its low leakage rate, which is less than one drop per minute (0.07 cc/min), making it ideal for applications where minimal fluid loss is critical. Constructed with a Delrin seat, the CXEBXFV is particularly suited for medium-pressure systems that may contain some level of contamination. It can handle up to 30 gallons per minute (120 L/min) and withstand pressures up to 3000 psi (210 bar). The valve's design incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model uses a T5A cavity and belongs to the Series 2 lineup from Sun Hydraulics. The valve has an installation torque requirement of 45-50 lbf ft (61-68 Nm) and weighs approximately 0.40 lb (0.20 kg). Its hex size measures at 1-1/8 inches (28.6 mm), ensuring compatibility with standard tools for installation and maintenance. The CXEBXFV is particularly beneficial in circuits where manifold drillings are incorrect, serving as a circuit saver by adapting to existing configurations without the need for extensive modifications. Additionally, it offers compatibility with Viton seal kits under part number 990203006, providing further customization and maintenance options tailored to specific operational requirements and environments.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
