SUN HYDRAULICS
CXEBXZV
$95.61 USD
- SUN HYDRAULICS
- Material:CXEBXZV
- Model:CXEB-XZV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEBXZV (CXEBXZV) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model allows free flow from the inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction, ensuring operational security and system integrity. The valve features a Delrin seat, making it suitable for applications involving dirty and medium-pressure systems that do not experience high flow rates or temperatures. With a capacity of 30 gallons per minute (120 liters per minute) and a maximum operating pressure of 3000 psi (210 bar), the CXEBXZV is built to handle substantial hydraulic loads. It offers exceptionally low leakage rates, with a maximum of less than one drop per minute (0.07 cc/min), which speaks to its efficiency and tight sealing capabilities. The model incorporates Sun\u2019s floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This check valve is particularly useful as a circuit saver in scenarios where existing manifold drillings are incorrect, providing flexibility in system design corrections without extensive modifications. Additionally, it shares the same cavity (T5A) for any given frame size within its series, although attention should be paid to potential differences in flow paths between two-port models. Installation specifications include a valve hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45-50 lbf ft (61-68 Nm). The unit's weight is modest at approximately 0.40 lb (0.20 kg), facilitating easier handling and integration into various setups.
The Sun Hydraulics CXEBXZV (CXEBXZV) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model allows free flow from the inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction, ensuring operational security and system integrity. The valve features a Delrin seat, making it suitable for applications involving dirty and medium-pressure systems that do not experience high flow rates or temperatures. With a capacity of 30 gallons per minute (120 liters per minute) and a maximum operating pressure of 3000 psi (210 bar), the CXEBXZV is built to handle substantial hydraulic loads. It offers exceptionally low leakage rates, with a maximum of less than one drop per minute (0.07 cc/min), which speaks to its efficiency and tight sealing capabilities. The model incorporates Sun\u2019s floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This check valve is particularly useful as a circuit saver in scenarios where existing manifold drillings are incorrect, providing flexibility in system design corrections without extensive modifications. Additionally, it shares the same cavity (T5A) for any given frame size within its series, although attention should be paid to potential differences in flow paths between two-port models. Installation specifications include a valve hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45-50 lbf ft (61-68 Nm). The unit's weight is modest at approximately 0.40 lb (0.20 kg), facilitating easier handling and integration into various setups.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
