SUN HYDRAULICS
CXECXAN
$73.37 USD
- SUN HYDRAULICS
- Material:CXECXAN
- Model:CXEC-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXECXAN (CXECXAN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a free-flow design from sidetoside, allowing fluid to pass freely from inlet port 2 to outlet port 1 while preventing backflow in the opposite direction. The valve is equipped with a Delrin seat, making it suitable for applications involving dirty and medium pressure systems, although it is not recommended for high flow or high temperature environments. The CXECXAN valve operates within a maximum pressure limit of 3000 psi (210 bar) and has a flow capacity of up to 30 gpm (120 L/min). It incorporates Sun Hydraulics' floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. The specific cavity required for this model is T5A, and it utilizes the Viton seal kit (990203006) ensuring excellent resistance against leaks with leakage rates less than 1 drop per minute (0.07 cc/min). Designed for ease of installation, the valve has a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). This model stands out as an effective solution for correcting existing circuit issues where manifold drillings are incorrect, offering about 30% less capacity compared to models with preferred nosetoside flow paths but still providing essential functionality as circuit savers in hydraulic systems.
The Sun Hydraulics CXECXAN (CXECXAN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a free-flow design from sidetoside, allowing fluid to pass freely from inlet port 2 to outlet port 1 while preventing backflow in the opposite direction. The valve is equipped with a Delrin seat, making it suitable for applications involving dirty and medium pressure systems, although it is not recommended for high flow or high temperature environments. The CXECXAN valve operates within a maximum pressure limit of 3000 psi (210 bar) and has a flow capacity of up to 30 gpm (120 L/min). It incorporates Sun Hydraulics' floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. The specific cavity required for this model is T5A, and it utilizes the Viton seal kit (990203006) ensuring excellent resistance against leaks with leakage rates less than 1 drop per minute (0.07 cc/min). Designed for ease of installation, the valve has a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). This model stands out as an effective solution for correcting existing circuit issues where manifold drillings are incorrect, offering about 30% less capacity compared to models with preferred nosetoside flow paths but still providing essential functionality as circuit savers in hydraulic systems.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
