SUN HYDRAULICS
CXECXBN
$72.37 USD
- SUN HYDRAULICS
- Material:CXECXBN
- Model:CXEC-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXECXBN (CXECXBN) is a high-performance hydraulic check valve designed for efficient flow control in medium pressure systems. This model features a Delrin seat, making it suitable for applications involving dirty conditions where the system is not exposed to high flows or temperatures. The CXECXBN allows free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction, ensuring reliable one-way operation. The check valve is built with a T5A cavity and belongs to the Series 2 line, supporting a maximum operating pressure of 3000 psi (210 bar) and a flow capacity of up to 30 gpm (120 L/min). It incorporates Sun\u2019s floating style construction which minimizes internal parts binding that could otherwise occur due to excessive installation torque or variations in cavity/cartridge machining. This design feature enhances the valve's operational reliability and lifespan. An important aspect of this model is its extremely low leakage rate, with less than one drop per minute (0.07 cc/min) being lost, making it an excellent choice for systems where fluid conservation and cleanliness are priorities. The CXECXBN is also noted for its ease of installation with a specified valve hex size of 1 1/8 inches (28.6 mm) and an installation torque range between 45 - 50 lbf ft (61 - 68 Nm). This two-port check valve uses Viton seals (part number: 990203006), known for their durability and resistance to high temperatures and chemicals, further ensuring the robustness and long service life of the valve under challenging conditions. The CXECXBN serves as an effective circuit saver particularly in scenarios where manifold drillings are incorrect, providing a practical solution without the need for extensive system modifications.
The Sun Hydraulics CXECXBN (CXECXBN) is a high-performance hydraulic check valve designed for efficient flow control in medium pressure systems. This model features a Delrin seat, making it suitable for applications involving dirty conditions where the system is not exposed to high flows or temperatures. The CXECXBN allows free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction, ensuring reliable one-way operation. The check valve is built with a T5A cavity and belongs to the Series 2 line, supporting a maximum operating pressure of 3000 psi (210 bar) and a flow capacity of up to 30 gpm (120 L/min). It incorporates Sun\u2019s floating style construction which minimizes internal parts binding that could otherwise occur due to excessive installation torque or variations in cavity/cartridge machining. This design feature enhances the valve's operational reliability and lifespan. An important aspect of this model is its extremely low leakage rate, with less than one drop per minute (0.07 cc/min) being lost, making it an excellent choice for systems where fluid conservation and cleanliness are priorities. The CXECXBN is also noted for its ease of installation with a specified valve hex size of 1 1/8 inches (28.6 mm) and an installation torque range between 45 - 50 lbf ft (61 - 68 Nm). This two-port check valve uses Viton seals (part number: 990203006), known for their durability and resistance to high temperatures and chemicals, further ensuring the robustness and long service life of the valve under challenging conditions. The CXECXBN serves as an effective circuit saver particularly in scenarios where manifold drillings are incorrect, providing a practical solution without the need for extensive system modifications.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
