SUN HYDRAULICS
CXECXBV
$78.83 USD
- SUN HYDRAULICS
- Material:CXECXBV
- Model:CXEC-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXECXBV (CXECXBV) is a two-port check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a free flow from the inlet port 2 to the outlet port 1, effectively blocking flow in the reverse direction, thus ensuring system integrity and preventing potential damage due to backflow. The valve is built with a Delrin seat which makes it particularly suitable for medium pressure systems that may contain some degree of contamination but do not experience extreme flows or temperatures. The CXECXBV operates within a maximum pressure limit of 3000 psi (210 bar) and has a flow capacity up to 30 gpm (120 L/min). Its construction includes the Sun floating style which minimizes internal parts binding, an issue that could arise from excessive installation torque or variations in cavity/cartridge machining. This design feature enhances the reliability and longevity of the valve under varied operational conditions. With an extremely low leakage rate of less than one drop per minute (0.07 cc/min), this model is an excellent choice for applications where minimal fluid loss is critical. It also shares the same cavity designation T5A across similar models, ensuring compatibility and interchangeability within systems using the same frame size. Installation specifications recommend a torque between 45 \u2013 50 lbf\u00b7ft (61 \u2013 68 Nm), with a hex size for the valve at 1-1/8 inches (28.6 mm). Overall, the Sun Hydraulics CXECXBV check valve is optimal for use in existing circuits needing correction for manifold drilling inaccuracies or where robust, low-leakage performance is necessary to maintain system efficiency and safety.
The Sun Hydraulics CXECXBV (CXECXBV) is a two-port check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a free flow from the inlet port 2 to the outlet port 1, effectively blocking flow in the reverse direction, thus ensuring system integrity and preventing potential damage due to backflow. The valve is built with a Delrin seat which makes it particularly suitable for medium pressure systems that may contain some degree of contamination but do not experience extreme flows or temperatures. The CXECXBV operates within a maximum pressure limit of 3000 psi (210 bar) and has a flow capacity up to 30 gpm (120 L/min). Its construction includes the Sun floating style which minimizes internal parts binding, an issue that could arise from excessive installation torque or variations in cavity/cartridge machining. This design feature enhances the reliability and longevity of the valve under varied operational conditions. With an extremely low leakage rate of less than one drop per minute (0.07 cc/min), this model is an excellent choice for applications where minimal fluid loss is critical. It also shares the same cavity designation T5A across similar models, ensuring compatibility and interchangeability within systems using the same frame size. Installation specifications recommend a torque between 45 \u2013 50 lbf\u00b7ft (61 \u2013 68 Nm), with a hex size for the valve at 1-1/8 inches (28.6 mm). Overall, the Sun Hydraulics CXECXBV check valve is optimal for use in existing circuits needing correction for manifold drilling inaccuracies or where robust, low-leakage performance is necessary to maintain system efficiency and safety.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
