SUN HYDRAULICS
CXECXCV
$76.84 USD
- SUN HYDRAULICS
- Material:CXECXCV
- Model:CXEC-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXECXCV (CXECXCV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a freeflow, side-to-nose configuration that allows free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction. With a maximum capacity of 30 gallons per minute (120 liters per minute) and an operating pressure up to 3000 psi (210 bar), the CXECXCV is well-suited for medium pressure systems that may contain dirty fluids. The valve incorporates a Delrin seat, making it appropriate for environments not exposed to high flows or temperatures, and where fluid cleanliness may be compromised. The design also includes Sun Hydraulics' floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This feature ensures consistent performance and longevity of the valve under varied installation conditions. The CXECXCV offers extremely low leakage rates, with a maximum leakage less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and efficient operation in critical applications. It is housed within a T5A cavity and can be installed using a hex size of 1-1/8 inches (28.6 mm) with an installation torque between 45-50 lbf\u00b7ft (61-68 Nm). The check valve uses Viton seals for enhanced durability and resistance against high temperatures and chemicals. This model is particularly useful as a circuit saver in existing systems where manifold drillings might be incorrect, providing flexibility and reliability without the need for extensive system modifications. Its straightforward design allows for easy integration into various hydraulic circuits, making it an essential component for maintaining unidirectional flow and preventing potential damage due to backflow.
The Sun Hydraulics CXECXCV (CXECXCV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a freeflow, side-to-nose configuration that allows free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction. With a maximum capacity of 30 gallons per minute (120 liters per minute) and an operating pressure up to 3000 psi (210 bar), the CXECXCV is well-suited for medium pressure systems that may contain dirty fluids. The valve incorporates a Delrin seat, making it appropriate for environments not exposed to high flows or temperatures, and where fluid cleanliness may be compromised. The design also includes Sun Hydraulics' floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This feature ensures consistent performance and longevity of the valve under varied installation conditions. The CXECXCV offers extremely low leakage rates, with a maximum leakage less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and efficient operation in critical applications. It is housed within a T5A cavity and can be installed using a hex size of 1-1/8 inches (28.6 mm) with an installation torque between 45-50 lbf\u00b7ft (61-68 Nm). The check valve uses Viton seals for enhanced durability and resistance against high temperatures and chemicals. This model is particularly useful as a circuit saver in existing systems where manifold drillings might be incorrect, providing flexibility and reliability without the need for extensive system modifications. Its straightforward design allows for easy integration into various hydraulic circuits, making it an essential component for maintaining unidirectional flow and preventing potential damage due to backflow.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
