SUN HYDRAULICS
CXECXEN
$70.39 USD
- SUN HYDRAULICS
- Material:CXECXEN
- Model:CXEC-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXECXEN (CXECXEN) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. The valve features a freeflow, side-to-nose configuration that allows free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction. This model is particularly suited for applications involving dirty or medium-pressure systems that do not experience high flows or temperatures, thanks to its Delrin seat which enhances durability under such conditions. The CXECXEN incorporates Sun\u2019s floating style construction which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This design feature ensures consistent performance and longevity of the valve even under challenging installation conditions. With a maximum operating pressure of 3000 psi (210 bar) and a flow capacity of 30 gpm (120 L/min), this check valve is capable of handling significant hydraulic loads while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min). This model uses a T5A cavity and requires a specific installation torque between 45 \u2013 50 lbf-ft (61 \u2013 68 Nm), ensuring secure and correct fitting into the hydraulic system. The valve's hex size is measured at 1 1/8 inches (28.6 mm), making it compatible with standard tools for installation and maintenance. It also supports Viton seals, as indicated by the seal kit/cartridge specification Viton: 990203006, which provides excellent resistance to high temperatures and chemical degradation, further enhancing the valve's reliability and service life in various industrial applications.
The Sun Hydraulics CXECXEN (CXECXEN) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. The valve features a freeflow, side-to-nose configuration that allows free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction. This model is particularly suited for applications involving dirty or medium-pressure systems that do not experience high flows or temperatures, thanks to its Delrin seat which enhances durability under such conditions. The CXECXEN incorporates Sun\u2019s floating style construction which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This design feature ensures consistent performance and longevity of the valve even under challenging installation conditions. With a maximum operating pressure of 3000 psi (210 bar) and a flow capacity of 30 gpm (120 L/min), this check valve is capable of handling significant hydraulic loads while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min). This model uses a T5A cavity and requires a specific installation torque between 45 \u2013 50 lbf-ft (61 \u2013 68 Nm), ensuring secure and correct fitting into the hydraulic system. The valve's hex size is measured at 1 1/8 inches (28.6 mm), making it compatible with standard tools for installation and maintenance. It also supports Viton seals, as indicated by the seal kit/cartridge specification Viton: 990203006, which provides excellent resistance to high temperatures and chemical degradation, further enhancing the valve's reliability and service life in various industrial applications.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
