SUN HYDRAULICS
CXECXFV
$78.83 USD
- SUN HYDRAULICS
- Material:CXECXFV
- Model:CXEC-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXECXFV (CXECXFV) is a high-performance check valve designed specifically for hydraulic systems requiring reliable one-way flow control. This model features a freeflow, side-to-nose check valve configuration that allows free flow from the inlet port 2 to the outlet port 1 while blocking flow in the reverse direction. The Delrin seat incorporated in this valve makes it particularly suitable for use in medium pressure systems that may contain some level of contamination, but do not experience extreme flows or temperatures. The CXECXFV operates within a maximum operating pressure of 3000 psi (210 bar) and has a flow capacity of up to 30 gpm (120 L/min). This two-port check valve fits a T5A cavity and utilizes Sun\u2019s floating style construction to prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. It also boasts an extremely low leakage rate, with maximum leakage less than one drop per minute (0.07 cc/min). For installation, the valve requires a hex size of 1-1/8 inches (28.6 mm) and an installation torque ranging between 45 - 50 lbf ft (61 - 68 Nm). The seal kit for this cartridge uses Viton material, ensuring durability and resistance against various fluids and temperatures within specified limits. Ideal for circuit correction applications where manifold drillings are incorrect, the CXECXFV provides an effective solution to enhance system reliability without extensive modifications.
The Sun Hydraulics CXECXFV (CXECXFV) is a high-performance check valve designed specifically for hydraulic systems requiring reliable one-way flow control. This model features a freeflow, side-to-nose check valve configuration that allows free flow from the inlet port 2 to the outlet port 1 while blocking flow in the reverse direction. The Delrin seat incorporated in this valve makes it particularly suitable for use in medium pressure systems that may contain some level of contamination, but do not experience extreme flows or temperatures. The CXECXFV operates within a maximum operating pressure of 3000 psi (210 bar) and has a flow capacity of up to 30 gpm (120 L/min). This two-port check valve fits a T5A cavity and utilizes Sun\u2019s floating style construction to prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. It also boasts an extremely low leakage rate, with maximum leakage less than one drop per minute (0.07 cc/min). For installation, the valve requires a hex size of 1-1/8 inches (28.6 mm) and an installation torque ranging between 45 - 50 lbf ft (61 - 68 Nm). The seal kit for this cartridge uses Viton material, ensuring durability and resistance against various fluids and temperatures within specified limits. Ideal for circuit correction applications where manifold drillings are incorrect, the CXECXFV provides an effective solution to enhance system reliability without extensive modifications.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
