SUN HYDRAULICS
CXECXZN
$74.36 USD
- SUN HYDRAULICS
- Material:CXECXZN
- Model:CXEC-XZN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXECXZN (CXECXZN) is a high-quality, two-port check valve designed for hydraulic systems. This model features free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction, making it an effective component for on-off circuit control. It incorporates a Delrin seat which enhances its suitability for medium pressure systems that encounter dirty conditions but not high flows or temperatures. The check valve's design allows it to be used as a circuit saver in existing circuits where manifold drilling errors have occurred. The CXECXZN model is specifically created to fit into a T5A cavity and belongs to the Series 2 line of Sun Hydraulics products. It can accommodate flows up to 30 gpm (120 L/min) and withstand maximum operating pressures up to 3000 psi (210 bar). Notably, this valve offers an impressively low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. Additionally, the valve features Sun's floating style construction which minimizes internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. The required installation torque for this valve is between 45 - 50 lbf.ft (61 - 68 Nm), and it has a hex size of 1-1/8 inches (28.6 mm). For maintenance or repairs, a Viton seal kit (990203006) is available for this model. This robust construction and thoughtful design make the CXECXZN check valve an excellent choice for hydraulic systems requiring reliable one-way flow control under varying operational conditions.
The Sun Hydraulics CXECXZN (CXECXZN) is a high-quality, two-port check valve designed for hydraulic systems. This model features free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction, making it an effective component for on-off circuit control. It incorporates a Delrin seat which enhances its suitability for medium pressure systems that encounter dirty conditions but not high flows or temperatures. The check valve's design allows it to be used as a circuit saver in existing circuits where manifold drilling errors have occurred. The CXECXZN model is specifically created to fit into a T5A cavity and belongs to the Series 2 line of Sun Hydraulics products. It can accommodate flows up to 30 gpm (120 L/min) and withstand maximum operating pressures up to 3000 psi (210 bar). Notably, this valve offers an impressively low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. Additionally, the valve features Sun's floating style construction which minimizes internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. The required installation torque for this valve is between 45 - 50 lbf.ft (61 - 68 Nm), and it has a hex size of 1-1/8 inches (28.6 mm). For maintenance or repairs, a Viton seal kit (990203006) is available for this model. This robust construction and thoughtful design make the CXECXZN check valve an excellent choice for hydraulic systems requiring reliable one-way flow control under varying operational conditions.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
