SUN HYDRAULICS
CXEDXEV
$44.38 USD
- SUN HYDRAULICS
- Material:CXEDXEV
- Model:CXED-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEDXEV (CXEDXEV) is a high-performance hydraulic check valve designed for robust and efficient operation in various hydraulic systems. This model is specifically engineered to allow free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction, making it an essential component for ensuring unidirectional flow and preventing potential damage due to backflow. The CXEDXEV valve operates with an impressive capacity of up to 30 gpm (120 L/min) and can withstand maximum operating pressures of up to 5000 psi (350 bar). This check valve features Sun Hydraulics' floating style construction which significantly reduces the risk of internal parts binding, a common issue caused by excessive installation torque or variations in cavity/cartridge machining. Such a design enhances the valve's reliability and longevity in demanding applications. Additionally, it offers extremely low leakage rates \u2014 less than 1 drop per minute (0.07 cc/min), ensuring efficient and leak-free operation. With a compact weight of just 0.40 lbs (0.20 kg) and designed for easy installation with a hex size of 1-1/8 inches (28.6 mm), this model promotes ease of use and maintenance. The required installation torque ranges between 45 - 50 lbf-ft (61 - 68 Nm), facilitating straightforward setup without the need for specialized tools or excessive force. The CXEDXEV is equipped with Viton seals, known for their high temperature and chemical resistance, further enhancing its suitability for challenging industrial environments where durability and reliability are paramount. This model's robust specifications make it ideal for applications requiring precise hydraulic flow control with minimal maintenance needs.
The Sun Hydraulics CXEDXEV (CXEDXEV) is a high-performance hydraulic check valve designed for robust and efficient operation in various hydraulic systems. This model is specifically engineered to allow free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction, making it an essential component for ensuring unidirectional flow and preventing potential damage due to backflow. The CXEDXEV valve operates with an impressive capacity of up to 30 gpm (120 L/min) and can withstand maximum operating pressures of up to 5000 psi (350 bar). This check valve features Sun Hydraulics' floating style construction which significantly reduces the risk of internal parts binding, a common issue caused by excessive installation torque or variations in cavity/cartridge machining. Such a design enhances the valve's reliability and longevity in demanding applications. Additionally, it offers extremely low leakage rates \u2014 less than 1 drop per minute (0.07 cc/min), ensuring efficient and leak-free operation. With a compact weight of just 0.40 lbs (0.20 kg) and designed for easy installation with a hex size of 1-1/8 inches (28.6 mm), this model promotes ease of use and maintenance. The required installation torque ranges between 45 - 50 lbf-ft (61 - 68 Nm), facilitating straightforward setup without the need for specialized tools or excessive force. The CXEDXEV is equipped with Viton seals, known for their high temperature and chemical resistance, further enhancing its suitability for challenging industrial environments where durability and reliability are paramount. This model's robust specifications make it ideal for applications requiring precise hydraulic flow control with minimal maintenance needs.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
