SUN HYDRAULICS
CXEEXAN
$54.11 USD
- SUN HYDRAULICS
- Material:CXEEXAN
- Model:CXEE-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXAN (CXEEXAN) is a specialized hydraulic check valve designed for high-performance and reliability in various hydraulic applications. This model utilizes a free-flow, side-to-nose cheater check valve configuration, typically used in circuits requiring a check valve within an existing three-port cavity. With the third port of the cartridge blocked off, it functions effectively as a standard 2-port check valve. The CXEEXAN model is engineered to accommodate up to 5000 psi (350 bar) at ports 1 and 2, ensuring robust operation under high-pressure conditions. This valve is distinguished by its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), contributing to enhanced efficiency and reduced wastage in hydraulic systems. It fits within a T2A cavity and supports a flow capacity of up to 30 gpm (120 L/min), making it suitable for substantial hydraulic flows. The construction of the CXEEXAN incorporates Sun\u2019s floating style design which minimizes internal part binding that can occur due to excessive installation torque or variations in cavity or cartridge machining. Additional features include corrosion resistance, vital for operations in corrosive environments, facilitated by specific model code suffixes like AP or LH. Installation specifications include a valve hex size of 1 1/8 in (28.6 mm) and an installation torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm). The overall weight of the model is modest at approximately .50 lb (0.25 kg), supporting ease of handling and installation. For maintenance or repairs, Viton seal kits are available under part number 990202006, ensuring long-term durability and performance consistency of the valve system.
The Sun Hydraulics CXEEXAN (CXEEXAN) is a specialized hydraulic check valve designed for high-performance and reliability in various hydraulic applications. This model utilizes a free-flow, side-to-nose cheater check valve configuration, typically used in circuits requiring a check valve within an existing three-port cavity. With the third port of the cartridge blocked off, it functions effectively as a standard 2-port check valve. The CXEEXAN model is engineered to accommodate up to 5000 psi (350 bar) at ports 1 and 2, ensuring robust operation under high-pressure conditions. This valve is distinguished by its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), contributing to enhanced efficiency and reduced wastage in hydraulic systems. It fits within a T2A cavity and supports a flow capacity of up to 30 gpm (120 L/min), making it suitable for substantial hydraulic flows. The construction of the CXEEXAN incorporates Sun\u2019s floating style design which minimizes internal part binding that can occur due to excessive installation torque or variations in cavity or cartridge machining. Additional features include corrosion resistance, vital for operations in corrosive environments, facilitated by specific model code suffixes like AP or LH. Installation specifications include a valve hex size of 1 1/8 in (28.6 mm) and an installation torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm). The overall weight of the model is modest at approximately .50 lb (0.25 kg), supporting ease of handling and installation. For maintenance or repairs, Viton seal kits are available under part number 990202006, ensuring long-term durability and performance consistency of the valve system.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
