SUN HYDRAULICS
CXEEXAV
$62.05 USD
- SUN HYDRAULICS
- Material:CXEEXAV
- Model:CXEE-XAV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXAV (CXEEXAV) is a specialized hydraulic check valve designed for high-pressure applications, capable of handling up to 5000 psi (350 bar) at ports 1 and 2. This model features a unique side-to-nose cheater check valve function within a three-port cavity, with port 3 blocked off, making it ideal for circuits requiring a check valve in an existing three-port setup. The CXEEXAV supports a flow capacity of up to 30 gpm (120 L/min), ensuring efficient operation in various hydraulic systems. One of the key attributes of the CXEEXAV is its extremely low leakage rate, which is less than one drop per minute (0.07 cc/min), contributing to enhanced system efficiency and reduced fluid loss. The valve is constructed using corrosion-resistant materials suitable for corrosive environments, and it incorporates Sun's floating style construction. This design minimizes internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. The CXEEXAV is housed in a T2A cavity and belongs to the Series 2 line of Sun Hydraulics products. It features a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). Additionally, the model weighs approximately 0.50 lb (0.25 kg), making it lightweight yet robust for industrial applications. For maintenance or repair, Viton seal kits are available under part number: 990202006. Overall, the Sun Hydraulics CXEEXAV check valve offers reliable performance with its advanced leakage control and high-pressure tolerance, suited for sophisticated hydraulic systems requiring precise fluid control.
The Sun Hydraulics CXEEXAV (CXEEXAV) is a specialized hydraulic check valve designed for high-pressure applications, capable of handling up to 5000 psi (350 bar) at ports 1 and 2. This model features a unique side-to-nose cheater check valve function within a three-port cavity, with port 3 blocked off, making it ideal for circuits requiring a check valve in an existing three-port setup. The CXEEXAV supports a flow capacity of up to 30 gpm (120 L/min), ensuring efficient operation in various hydraulic systems. One of the key attributes of the CXEEXAV is its extremely low leakage rate, which is less than one drop per minute (0.07 cc/min), contributing to enhanced system efficiency and reduced fluid loss. The valve is constructed using corrosion-resistant materials suitable for corrosive environments, and it incorporates Sun's floating style construction. This design minimizes internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. The CXEEXAV is housed in a T2A cavity and belongs to the Series 2 line of Sun Hydraulics products. It features a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). Additionally, the model weighs approximately 0.50 lb (0.25 kg), making it lightweight yet robust for industrial applications. For maintenance or repair, Viton seal kits are available under part number: 990202006. Overall, the Sun Hydraulics CXEEXAV check valve offers reliable performance with its advanced leakage control and high-pressure tolerance, suited for sophisticated hydraulic systems requiring precise fluid control.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
