SUN HYDRAULICS
CXEEXBN
$53.11 USD
- SUN HYDRAULICS
- Material:CXEEXBN
- Model:CXEE-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXBN (CXEEXBN) is a versatile and efficient hydraulic check valve designed for high-pressure applications up to 5000 psi (350 bar). This model stands out due to its unique free-flow, side-to-nose cheater check valve functionality, which allows it to operate as a standard 2-port check valve while fitting into a 3-port cavity with one port blocked. This design makes it particularly useful for adapting existing systems that require a check valve in a three-port setup. The CXEEXBN features extremely low leakage rates, with maximum leakage less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. Constructed to fit the T2A cavity and part of the Series 2 lineup, the CXEEXBN can handle flow capacities up to 30 gpm (120 L/min). Its robust design includes Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This feature not only extends the valve's lifespan but also ensures reliable operation under varying conditions. The valve is corrosion-resistant, making it suitable for use in environments where corrosion is a concern. It requires an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm) and has a compact weight of just 0.50 lb (0.25 kg). The hex size for the valve is 1-1/8 inches (28.6 mm), and it utilizes Viton seals for enhanced durability against harsh fluids and high temperatures. This model's reliability and adaptability make it an excellent choice for hydraulic systems requiring precise flow control and minimal leakage in a compact form factor.
The Sun Hydraulics CXEEXBN (CXEEXBN) is a versatile and efficient hydraulic check valve designed for high-pressure applications up to 5000 psi (350 bar). This model stands out due to its unique free-flow, side-to-nose cheater check valve functionality, which allows it to operate as a standard 2-port check valve while fitting into a 3-port cavity with one port blocked. This design makes it particularly useful for adapting existing systems that require a check valve in a three-port setup. The CXEEXBN features extremely low leakage rates, with maximum leakage less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. Constructed to fit the T2A cavity and part of the Series 2 lineup, the CXEEXBN can handle flow capacities up to 30 gpm (120 L/min). Its robust design includes Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This feature not only extends the valve's lifespan but also ensures reliable operation under varying conditions. The valve is corrosion-resistant, making it suitable for use in environments where corrosion is a concern. It requires an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm) and has a compact weight of just 0.50 lb (0.25 kg). The hex size for the valve is 1-1/8 inches (28.6 mm), and it utilizes Viton seals for enhanced durability against harsh fluids and high temperatures. This model's reliability and adaptability make it an excellent choice for hydraulic systems requiring precise flow control and minimal leakage in a compact form factor.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
