SUN HYDRAULICS
CXEEXBV
$61.05 USD
- SUN HYDRAULICS
- Material:CXEEXBV
- Model:CXEE-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXBV (CXEEXBV) is a versatile hydraulic check valve designed for high-pressure applications, capable of handling up to 5000 psi (350 bar) at ports 1 and 2. This model is particularly suitable for systems requiring a reliable check valve in a three-port cavity configuration, with the third port blocked off. The CXEEXBV features a free flow, side-to-nose cheater check valve function, which makes it ideal for circuits where traditional two-port check valves are necessary but space or existing configurations demand a three-port solution. The valve ensures minimal leakage, maintaining integrity with less than one drop per minute (0.07 cc/min) leakage rate, which is crucial for maintaining system efficiency and preventing fluid loss. It also incorporates Sun's floating style construction which reduces the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. With a maximum capacity of 30 gpm (120 L/min), the CXEEXBV is built to accommodate substantial flow rates, making it suitable for various industrial hydraulic applications. The model is also designed with corrosion resistance in mind, indicated by specific model code suffixes (AP or LH) that denote the types of environments it can endure. For installation, the valve requires a hex size of 1-1/8 inches (28.6 mm) and an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm). Weighing just 0.50 lb (0.25 kg), this model combines lightweight design with robust performance and reliability. The use of Viton seals ensures enhanced durability against high temperatures and chemical exposure, further enhancing its suitability across diverse operational conditions.
The Sun Hydraulics CXEEXBV (CXEEXBV) is a versatile hydraulic check valve designed for high-pressure applications, capable of handling up to 5000 psi (350 bar) at ports 1 and 2. This model is particularly suitable for systems requiring a reliable check valve in a three-port cavity configuration, with the third port blocked off. The CXEEXBV features a free flow, side-to-nose cheater check valve function, which makes it ideal for circuits where traditional two-port check valves are necessary but space or existing configurations demand a three-port solution. The valve ensures minimal leakage, maintaining integrity with less than one drop per minute (0.07 cc/min) leakage rate, which is crucial for maintaining system efficiency and preventing fluid loss. It also incorporates Sun's floating style construction which reduces the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. With a maximum capacity of 30 gpm (120 L/min), the CXEEXBV is built to accommodate substantial flow rates, making it suitable for various industrial hydraulic applications. The model is also designed with corrosion resistance in mind, indicated by specific model code suffixes (AP or LH) that denote the types of environments it can endure. For installation, the valve requires a hex size of 1-1/8 inches (28.6 mm) and an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm). Weighing just 0.50 lb (0.25 kg), this model combines lightweight design with robust performance and reliability. The use of Viton seals ensures enhanced durability against high temperatures and chemical exposure, further enhancing its suitability across diverse operational conditions.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
