SUN HYDRAULICS
CXEEXCN
$51.13 USD
- SUN HYDRAULICS
- Material:CXEEXCN
- Model:CXEE-XCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXCN (CXEEXCN) is a highly functional check valve designed for hydraulic systems requiring reliable, low-leakage flow control in a three-port cavity setup. This product is especially useful for applications where a standard two-port check valve needs to be implemented within an existing three-port configuration by blocking off the third port. The CXEEXCN valve is engineered to handle a maximum operating pressure of 5000 psi (350 bar) at ports 1 and 2, accommodating flow capacities up to 30 gpm (120 L/min). Notably, the CXEEXCN features an extremely low leakage rate, with a maximum of less than one drop per minute (0.07 cc/min), ensuring efficient and clean operation critical in maintaining system integrity and performance. The valve's design incorporates Sun's floating style construction which minimizes the risk of internal parts binding\u2014a common issue arising from excessive installation torque or machining variations within the cavity/cartridge. This model also stands out due to its corrosion-resistant capabilities, making it suitable for use in environments where exposure to corrosive elements is a concern. The model's robust construction includes a hex size of 1 1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). Weighing just 0.50 lb (0.25 kg), the CXEEXCN remains lightweight yet durable enough for demanding applications. It also supports Viton seal kits for enhanced sealing efficiency under various conditions. Overall, the Sun Hydraulics CXEEXCN check valve offers reliability and versatility for hydraulic systems needing precise flow control with minimal leakage and high resistance to environmental challenges.
The Sun Hydraulics CXEEXCN (CXEEXCN) is a highly functional check valve designed for hydraulic systems requiring reliable, low-leakage flow control in a three-port cavity setup. This product is especially useful for applications where a standard two-port check valve needs to be implemented within an existing three-port configuration by blocking off the third port. The CXEEXCN valve is engineered to handle a maximum operating pressure of 5000 psi (350 bar) at ports 1 and 2, accommodating flow capacities up to 30 gpm (120 L/min). Notably, the CXEEXCN features an extremely low leakage rate, with a maximum of less than one drop per minute (0.07 cc/min), ensuring efficient and clean operation critical in maintaining system integrity and performance. The valve's design incorporates Sun's floating style construction which minimizes the risk of internal parts binding\u2014a common issue arising from excessive installation torque or machining variations within the cavity/cartridge. This model also stands out due to its corrosion-resistant capabilities, making it suitable for use in environments where exposure to corrosive elements is a concern. The model's robust construction includes a hex size of 1 1/8 inches (28.6 mm) and requires an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). Weighing just 0.50 lb (0.25 kg), the CXEEXCN remains lightweight yet durable enough for demanding applications. It also supports Viton seal kits for enhanced sealing efficiency under various conditions. Overall, the Sun Hydraulics CXEEXCN check valve offers reliability and versatility for hydraulic systems needing precise flow control with minimal leakage and high resistance to environmental challenges.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
