SUN HYDRAULICS
CXEEXCV
$59.07 USD
- SUN HYDRAULICS
- Material:CXEEXCV
- Model:CXEE-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXCV (CXEEXCV) is a versatile hydraulic check valve designed for high-pressure applications up to 5000 psi (350 bar). This model is particularly unique as it functions as a standard 2-port check valve within a 3-port cavity configuration, with port 3 blocked off. This design allows it to be easily integrated into existing three-port cavity systems, making it ideal for retrofitting or upgrading without the need for extensive modifications. The CXEEXCV model features extremely low leakage rates, ensuring that no more than one drop per minute (0.07 cc/min) is lost, which enhances system efficiency and reduces waste. Constructed to handle flow capacities up to 30 gpm (120 L/min), the CXEEXCV valve is suitable for a wide range of fluid dynamics applications. Its corrosion-resistant cartridge is specifically designed for use in corrosive environments, extending its usability and durability under harsh conditions. The valve also incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model requires an installation torque of between 45 - 50 lbf ft (61 - 68 Nm) and has a hex size of 1-1/8 inches (28.6 mm). Weighing just .50 lb (0.25 kg), the CXEEXCV offers a compact yet robust solution for hydraulic systems requiring reliable check valves with minimal space and weight impact. The use of Viton seals further ensures compatibility with a wide range of fluids and enhanced sealing performance under variable temperatures and pressures.
The Sun Hydraulics CXEEXCV (CXEEXCV) is a versatile hydraulic check valve designed for high-pressure applications up to 5000 psi (350 bar). This model is particularly unique as it functions as a standard 2-port check valve within a 3-port cavity configuration, with port 3 blocked off. This design allows it to be easily integrated into existing three-port cavity systems, making it ideal for retrofitting or upgrading without the need for extensive modifications. The CXEEXCV model features extremely low leakage rates, ensuring that no more than one drop per minute (0.07 cc/min) is lost, which enhances system efficiency and reduces waste. Constructed to handle flow capacities up to 30 gpm (120 L/min), the CXEEXCV valve is suitable for a wide range of fluid dynamics applications. Its corrosion-resistant cartridge is specifically designed for use in corrosive environments, extending its usability and durability under harsh conditions. The valve also incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model requires an installation torque of between 45 - 50 lbf ft (61 - 68 Nm) and has a hex size of 1-1/8 inches (28.6 mm). Weighing just .50 lb (0.25 kg), the CXEEXCV offers a compact yet robust solution for hydraulic systems requiring reliable check valves with minimal space and weight impact. The use of Viton seals further ensures compatibility with a wide range of fluids and enhanced sealing performance under variable temperatures and pressures.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
