SUN HYDRAULICS
CXEEXDN
$53.11 USD
- SUN HYDRAULICS
- Material:CXEEXDN
- Model:CXEE-XDN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXDN (CXEEXDN) is a specialized hydraulic check valve designed for high-pressure applications, supporting a maximum operating pressure of 5000 psi (350 bar). This valve is crafted to function as a standard 2-port check valve within a 3-port cavity, with the third port effectively blocked off. This design feature makes it particularly useful in circuits that require a check valve in an existing three-port cavity setup. The CXEEXDN model exhibits extremely low leakage rates, with maximum leakage constrained to less than one drop per minute (0.07 cc/min), ensuring efficient and reliable operation. The valve's construction includes Sun Hydraulics' floating style, which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This innovative design enhances the durability and performance stability of the valve under various operational conditions. The CXEEXDN is also designed to be corrosion-resistant, suitable for use in environments where corrosion could pose a significant issue. In terms of physical specifications, the CXEEXDN has a flow capacity of up to 30 gpm (120 L/min) and features a hex size of 1 1/8 inches (28.6 mm). The recommended installation torque is between 45 - 50 lbf\u00b7ft (61 - 68 Nm), and it weighs approximately 0.50 lb (0.25 kg). This model uses Viton seals for enhanced resistance against high temperatures and chemical degradation, making it an ideal choice for challenging industrial applications where hydraulic efficiency and reliability are paramount.
The Sun Hydraulics CXEEXDN (CXEEXDN) is a specialized hydraulic check valve designed for high-pressure applications, supporting a maximum operating pressure of 5000 psi (350 bar). This valve is crafted to function as a standard 2-port check valve within a 3-port cavity, with the third port effectively blocked off. This design feature makes it particularly useful in circuits that require a check valve in an existing three-port cavity setup. The CXEEXDN model exhibits extremely low leakage rates, with maximum leakage constrained to less than one drop per minute (0.07 cc/min), ensuring efficient and reliable operation. The valve's construction includes Sun Hydraulics' floating style, which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This innovative design enhances the durability and performance stability of the valve under various operational conditions. The CXEEXDN is also designed to be corrosion-resistant, suitable for use in environments where corrosion could pose a significant issue. In terms of physical specifications, the CXEEXDN has a flow capacity of up to 30 gpm (120 L/min) and features a hex size of 1 1/8 inches (28.6 mm). The recommended installation torque is between 45 - 50 lbf\u00b7ft (61 - 68 Nm), and it weighs approximately 0.50 lb (0.25 kg). This model uses Viton seals for enhanced resistance against high temperatures and chemical degradation, making it an ideal choice for challenging industrial applications where hydraulic efficiency and reliability are paramount.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
