SUN HYDRAULICS
CXEEXDV
$61.05 USD
- SUN HYDRAULICS
- Material:CXEEXDV
- Model:CXEE-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXDV (CXEEXDV) is a specialized hydraulic check valve designed for high-performance and reliability in various hydraulic applications. This valve incorporates Sun\u2019s innovative floating style construction, which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. It is constructed to operate under a maximum pressure of 5000 psi (350 bar) at ports 1 and 2, ensuring robust performance even under demanding conditions. The CXEEXDV model has a unique feature as it functions as a standard 2-port check valve within a 3-port cavity with port 3 blocked off, making it versatile for use in circuits originally designed for three ports but only requiring two. This capability allows for simplified adaptations without the need for extensive modifications to existing systems. The valve supports a flow capacity of up to 30 gpm (120 L/min), catering efficiently to substantial hydraulic flows. A noteworthy aspect of this model is its exceptionally low leakage rate, with maximum leakage limited to less than one drop per minute (0.07 cc/min), which promotes system efficiency and reduces fluid loss. The valve's hex size is 1-1/8 inches (28.6 mm), and it requires an installation torque between 45 and 50 lbf-ft (61 - 68 Nm), facilitating easy installation while ensuring secure fitting. Weighing just about .50 lb (0.25 kg), the CXEEXDV model is lightweight yet durable, crafted from materials that resist corrosion even in harsh environments. Additionally, the CXEEXDV uses Viton seals (990202006) for enhanced chemical resistance and durability, further extending its usability across various operating conditions without compromising on performance or safety. This check valve by Sun Hydraulics stands out as an efficient solution tailored for effective fluid control in industrial hydraulics systems.
The Sun Hydraulics CXEEXDV (CXEEXDV) is a specialized hydraulic check valve designed for high-performance and reliability in various hydraulic applications. This valve incorporates Sun\u2019s innovative floating style construction, which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. It is constructed to operate under a maximum pressure of 5000 psi (350 bar) at ports 1 and 2, ensuring robust performance even under demanding conditions. The CXEEXDV model has a unique feature as it functions as a standard 2-port check valve within a 3-port cavity with port 3 blocked off, making it versatile for use in circuits originally designed for three ports but only requiring two. This capability allows for simplified adaptations without the need for extensive modifications to existing systems. The valve supports a flow capacity of up to 30 gpm (120 L/min), catering efficiently to substantial hydraulic flows. A noteworthy aspect of this model is its exceptionally low leakage rate, with maximum leakage limited to less than one drop per minute (0.07 cc/min), which promotes system efficiency and reduces fluid loss. The valve's hex size is 1-1/8 inches (28.6 mm), and it requires an installation torque between 45 and 50 lbf-ft (61 - 68 Nm), facilitating easy installation while ensuring secure fitting. Weighing just about .50 lb (0.25 kg), the CXEEXDV model is lightweight yet durable, crafted from materials that resist corrosion even in harsh environments. Additionally, the CXEEXDV uses Viton seals (990202006) for enhanced chemical resistance and durability, further extending its usability across various operating conditions without compromising on performance or safety. This check valve by Sun Hydraulics stands out as an efficient solution tailored for effective fluid control in industrial hydraulics systems.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
