SUN HYDRAULICS
CXEEXEN
$51.13 USD
- SUN HYDRAULICS
- Material:CXEEXEN
- Model:CXEE-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXEN (CXEEXEN) is a versatile hydraulic check valve designed for high-pressure applications. Featuring a unique free-flow, side-to-nose \"cheater\" check valve function, this model operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port blocked off. This design makes it ideal for retrofitting into existing three-port cavities where only a check valve function is needed. The CXEEXEN model boasts an impressive maximum operating pressure of 5000 psi (350 bar) at ports 1 and 2, accommodating flow rates up to 30 gpm (120 L/min), making it suitable for various high-pressure hydraulic systems. The valve ensures minimal leakage, maintaining less than one drop per minute (0.07 cc/min), which underscores its efficiency and reliability in maintaining system integrity. Constructed to resist corrosion, the CXEEXEN employs Sun's floating style construction which reduces the risk of internal parts binding\u2014a common issue resulting from excessive installation torque or machining variations in the cavity or cartridge. This model also supports easy installation with specific torque requirements ranging between 45 - 50 lbf ft (61 - 68 Nm), and it has a compact form factor with a weight of just .50 lb (0.25 kg). Additionally, this model utilizes Viton seals for enhanced durability and performance under various environmental conditions. The CXEEXEN is equipped to handle demanding applications requiring precise flow control and reliability in corrosive environments or systems where space and existing configurations limit modification options.
The Sun Hydraulics CXEEXEN (CXEEXEN) is a versatile hydraulic check valve designed for high-pressure applications. Featuring a unique free-flow, side-to-nose \"cheater\" check valve function, this model operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port blocked off. This design makes it ideal for retrofitting into existing three-port cavities where only a check valve function is needed. The CXEEXEN model boasts an impressive maximum operating pressure of 5000 psi (350 bar) at ports 1 and 2, accommodating flow rates up to 30 gpm (120 L/min), making it suitable for various high-pressure hydraulic systems. The valve ensures minimal leakage, maintaining less than one drop per minute (0.07 cc/min), which underscores its efficiency and reliability in maintaining system integrity. Constructed to resist corrosion, the CXEEXEN employs Sun's floating style construction which reduces the risk of internal parts binding\u2014a common issue resulting from excessive installation torque or machining variations in the cavity or cartridge. This model also supports easy installation with specific torque requirements ranging between 45 - 50 lbf ft (61 - 68 Nm), and it has a compact form factor with a weight of just .50 lb (0.25 kg). Additionally, this model utilizes Viton seals for enhanced durability and performance under various environmental conditions. The CXEEXEN is equipped to handle demanding applications requiring precise flow control and reliability in corrosive environments or systems where space and existing configurations limit modification options.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
