SUN HYDRAULICS
CXEEXFN
$53.11 USD
- SUN HYDRAULICS
- Material:CXEEXFN
- Model:CXEE-XFN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXFN (CXEEXFN) is a free-flow, side-to-nose cheater check valve designed for versatile applications in hydraulic systems. This model operates effectively as a standard 2-port check valve within a 3-port cavity, with the third port blocked off, making it ideal for circuits that require a check valve in an existing three-port setup. The CXEEXFN ensures minimal leakage, with a maximum rate of less than 1 drop per minute (0.07 cc/min), and can withstand up to 5000 psi (350 bar) at ports 1 and 2. This valve is built to resist corrosion, suitable for corrosive environments due to its robust construction. It features Sun's floating style construction which minimizes internal parts binding, a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The CXEEXFN fits into a T2A cavity and is part of the Series 2 line, offering a flow capacity of up to 30 gpm (120 L/min). Key specifications include a maximum operating pressure of 5000 psi (350 bar), hex size of 1-1/8 inches (28.6 mm), and an installation torque range of 45-50 lbf\u00b7ft (61-68 Nm). Weighing just about .50 lb (0.25 kg), this model is compact yet powerful. This valve is also equipped with Viton seals (990202006) ensuring durability and resilience under various operating conditions. The CXEEXFN model by Sun Hydraulics provides reliability and high performance for hydraulic systems requiring precise flow control and minimal fluid loss in challenging environments.
The Sun Hydraulics CXEEXFN (CXEEXFN) is a free-flow, side-to-nose cheater check valve designed for versatile applications in hydraulic systems. This model operates effectively as a standard 2-port check valve within a 3-port cavity, with the third port blocked off, making it ideal for circuits that require a check valve in an existing three-port setup. The CXEEXFN ensures minimal leakage, with a maximum rate of less than 1 drop per minute (0.07 cc/min), and can withstand up to 5000 psi (350 bar) at ports 1 and 2. This valve is built to resist corrosion, suitable for corrosive environments due to its robust construction. It features Sun's floating style construction which minimizes internal parts binding, a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The CXEEXFN fits into a T2A cavity and is part of the Series 2 line, offering a flow capacity of up to 30 gpm (120 L/min). Key specifications include a maximum operating pressure of 5000 psi (350 bar), hex size of 1-1/8 inches (28.6 mm), and an installation torque range of 45-50 lbf\u00b7ft (61-68 Nm). Weighing just about .50 lb (0.25 kg), this model is compact yet powerful. This valve is also equipped with Viton seals (990202006) ensuring durability and resilience under various operating conditions. The CXEEXFN model by Sun Hydraulics provides reliability and high performance for hydraulic systems requiring precise flow control and minimal fluid loss in challenging environments.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
