SUN HYDRAULICS
CXEEXFV
$61.05 USD
- SUN HYDRAULICS
- Material:CXEEXFV
- Model:CXEE-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXFV (CXEEXFV) is a highly innovative and functional hydraulic check valve designed for specialized applications. This model features a unique freeflow, side-to-nose cheater check valve mechanism which operates as a standard 2-port check valve in a 3-port cavity configuration, with the third port effectively blocked off. This design allows it to be used in circuits where a check valve is essential but only a three-port cavity is available, thus providing flexibility in usage without the need for additional modifications. The CXEEXFV is engineered to support high-pressure operations with an impressive capacity of up to 5000 psi (350 bar) at ports 1 and 2 and can handle flow rates up to 30 gpm (120 L/min). Its robust construction ensures minimal leakage, maintaining less than one drop per minute (0.07 cc/min), which signifies its efficiency and reliability in maintaining system integrity. The model also incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This valve is designed with corrosion resistance in mind, suitable for environments where corrosive elements are present. Its compact size (.50 lb/0.25 kg) and specific installation requirements (45-50 lbf ft/61-68 Nm torque) make it easy to integrate into various setups without significant alterations. The T2A cavity design and Series 2 specifications further enhance its adaptability across different systems. The use of Viton seals ensures long-term durability and resistance against various fluids and temperatures, making the CXEEXFV an excellent choice for a wide range of hydraulic applications requiring precise flow control and reliability.
The Sun Hydraulics CXEEXFV (CXEEXFV) is a highly innovative and functional hydraulic check valve designed for specialized applications. This model features a unique freeflow, side-to-nose cheater check valve mechanism which operates as a standard 2-port check valve in a 3-port cavity configuration, with the third port effectively blocked off. This design allows it to be used in circuits where a check valve is essential but only a three-port cavity is available, thus providing flexibility in usage without the need for additional modifications. The CXEEXFV is engineered to support high-pressure operations with an impressive capacity of up to 5000 psi (350 bar) at ports 1 and 2 and can handle flow rates up to 30 gpm (120 L/min). Its robust construction ensures minimal leakage, maintaining less than one drop per minute (0.07 cc/min), which signifies its efficiency and reliability in maintaining system integrity. The model also incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This valve is designed with corrosion resistance in mind, suitable for environments where corrosive elements are present. Its compact size (.50 lb/0.25 kg) and specific installation requirements (45-50 lbf ft/61-68 Nm torque) make it easy to integrate into various setups without significant alterations. The T2A cavity design and Series 2 specifications further enhance its adaptability across different systems. The use of Viton seals ensures long-term durability and resistance against various fluids and temperatures, making the CXEEXFV an excellent choice for a wide range of hydraulic applications requiring precise flow control and reliability.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
