SUN HYDRAULICS
CXEEXZN
$55.10 USD
- SUN HYDRAULICS
- Material:CXEEXZN
- Model:CXEE-XZN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEEXZN (CXEEXZN) is a specialized hydraulic check valve designed for high-performance applications where minimal leakage and high pressure are critical. This valve is uniquely configured as a free-flow, side-to-nose cheater check valve, functioning as a standard 2-port check valve within a 3-port cavity setup, with the third port blocked off. This design allows for its use in circuits that originally contain a three-port cavity but only require a two-port check valve functionality. The CXEEXZN model boasts an impressive maximum operating pressure of 5000 psi (350 bar) at ports 1 and 2, making it suitable for heavy-duty operations. It ensures an extremely low leakage rate of less than one drop per minute (0.07 cc/min), which is crucial for maintaining system efficiency and preventing fluid loss in critical applications. The valve's capacity to handle up to 30 gpm (120 L/min) further underscores its robust performance in various hydraulic systems. Constructed with corrosion-resistant materials, the CXEEXZN ensures durability and longevity even in corrosive environments. Its floating style construction minimizes the risk of internal parts binding, which can occur due to excessive installation torque or variations in cavity/cartridge machining. The model comes with Viton seals (990202006), enhancing its resistance against harsh fluids and temperatures. For installation, the valve requires a hex size of 1 1/8 inches (28.6 mm) and an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm). Weighing at just .50 lb (0.25 kg), it offers ease of handling and integration into existing hydraulic systems without significant modifications. In summary, the Sun Hydraulics CXEEXZN check valve is an efficient solution tailored for systems needing reliable backflow prevention with minimal fluid leakage in a compact three-port configuration adapted to two-port use.
The Sun Hydraulics CXEEXZN (CXEEXZN) is a specialized hydraulic check valve designed for high-performance applications where minimal leakage and high pressure are critical. This valve is uniquely configured as a free-flow, side-to-nose cheater check valve, functioning as a standard 2-port check valve within a 3-port cavity setup, with the third port blocked off. This design allows for its use in circuits that originally contain a three-port cavity but only require a two-port check valve functionality. The CXEEXZN model boasts an impressive maximum operating pressure of 5000 psi (350 bar) at ports 1 and 2, making it suitable for heavy-duty operations. It ensures an extremely low leakage rate of less than one drop per minute (0.07 cc/min), which is crucial for maintaining system efficiency and preventing fluid loss in critical applications. The valve's capacity to handle up to 30 gpm (120 L/min) further underscores its robust performance in various hydraulic systems. Constructed with corrosion-resistant materials, the CXEEXZN ensures durability and longevity even in corrosive environments. Its floating style construction minimizes the risk of internal parts binding, which can occur due to excessive installation torque or variations in cavity/cartridge machining. The model comes with Viton seals (990202006), enhancing its resistance against harsh fluids and temperatures. For installation, the valve requires a hex size of 1 1/8 inches (28.6 mm) and an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm). Weighing at just .50 lb (0.25 kg), it offers ease of handling and integration into existing hydraulic systems without significant modifications. In summary, the Sun Hydraulics CXEEXZN check valve is an efficient solution tailored for systems needing reliable backflow prevention with minimal fluid leakage in a compact three-port configuration adapted to two-port use.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
