SUN HYDRAULICS
CXFAXAE
$130.36 USD
- SUN HYDRAULICS
- Material:CXFAXAE
- Model:CXFA-XAE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXFAXAE (CXFAXAE) is a high-performance hydraulic check valve designed for robust fluid control in various applications. This model is particularly noted for its free-flow functionality, allowing fluid to pass freely from the inlet port 1 to the outlet port 2 while blocking reverse flow. The CXFAXAE operates effectively under a maximum operating pressure of 5000 psi (350 bar) and can handle a flow capacity up to 40 gpm (160 L/min), making it suitable for high-pressure systems. The valve features extremely low leakage rates, less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. It is built with a T5A cavity and adheres to Series 2 specifications, which users need to consider when integrating into existing systems due to potential variations in flow paths among different models. For environments involving corrosive substances or requiring higher resistance, the CXFAXAE includes options with EPDM seals designed specifically for use with phosphate ester fluids; however, these are sensitive to petroleum-based products which may cause damage. Additionally, the model incorporates Sun's unique floating style construction that minimizes internal binding risks caused by over-torquing during installation or variances in machining. The physical specifications include a valve hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45 - 50 lbf ft (61 - 68 Nm). Weighing only about 0.40 lb (0.20 kg), this valve combines lightweight design with durable performance, optimized for reliable operation across various hydraulic applications where check valves are essential components.
The Sun Hydraulics CXFAXAE (CXFAXAE) is a high-performance hydraulic check valve designed for robust fluid control in various applications. This model is particularly noted for its free-flow functionality, allowing fluid to pass freely from the inlet port 1 to the outlet port 2 while blocking reverse flow. The CXFAXAE operates effectively under a maximum operating pressure of 5000 psi (350 bar) and can handle a flow capacity up to 40 gpm (160 L/min), making it suitable for high-pressure systems. The valve features extremely low leakage rates, less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. It is built with a T5A cavity and adheres to Series 2 specifications, which users need to consider when integrating into existing systems due to potential variations in flow paths among different models. For environments involving corrosive substances or requiring higher resistance, the CXFAXAE includes options with EPDM seals designed specifically for use with phosphate ester fluids; however, these are sensitive to petroleum-based products which may cause damage. Additionally, the model incorporates Sun's unique floating style construction that minimizes internal binding risks caused by over-torquing during installation or variances in machining. The physical specifications include a valve hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45 - 50 lbf ft (61 - 68 Nm). Weighing only about 0.40 lb (0.20 kg), this valve combines lightweight design with durable performance, optimized for reliable operation across various hydraulic applications where check valves are essential components.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 40 gpm160 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
