SUN HYDRAULICS
CXFAXCE
$130.36 USD
- SUN HYDRAULICS
- Material:CXFAXCE
- Model:CXFA-XCE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXFAXCE (CXFAXCE) is a robust check valve designed for hydraulic applications requiring reliable, one-way flow control. This model, part of Sun Hydraulics' T5A cavity series, features a two-port configuration that supports a flow capacity up to 40 gpm (160 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). The valve ensures minimal leakage, maintaining less than one drop per minute (0.07 cc/min), which underscores its efficiency in preventing fluid loss. Notably, the CXFAXCE valve incorporates Sun's floating style construction. This design choice minimizes the risk of internal parts binding which can occur due to excessive installation torque or variations in cavity/cartridge machining. It is crucial for users to note that cartridges configured with EPDM seals are specifically intended for use with phosphate ester fluids; exposure to petroleum-based fluids can damage these seals. The model's durability is further enhanced by options for corrosion-resistant configurations, denoted by suffixes AP or LH in the model code, making it suitable for use in corrosive environments. For installation, the valve requires a hex size of 1 1/8 inches (28.6 mm) and an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). The compact unit weighs approximately 0.40 lbs (0.20 kg), facilitating ease of handling and integration into various hydraulic systems without adding significant weight. In summary, the Sun Hydraulics CXFAXCE check valve is engineered for high-pressure applications where fluid control and leakage prevention are paramount, packaged in a design that ensures long-term reliability and performance under challenging conditions.
The Sun Hydraulics CXFAXCE (CXFAXCE) is a robust check valve designed for hydraulic applications requiring reliable, one-way flow control. This model, part of Sun Hydraulics' T5A cavity series, features a two-port configuration that supports a flow capacity up to 40 gpm (160 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). The valve ensures minimal leakage, maintaining less than one drop per minute (0.07 cc/min), which underscores its efficiency in preventing fluid loss. Notably, the CXFAXCE valve incorporates Sun's floating style construction. This design choice minimizes the risk of internal parts binding which can occur due to excessive installation torque or variations in cavity/cartridge machining. It is crucial for users to note that cartridges configured with EPDM seals are specifically intended for use with phosphate ester fluids; exposure to petroleum-based fluids can damage these seals. The model's durability is further enhanced by options for corrosion-resistant configurations, denoted by suffixes AP or LH in the model code, making it suitable for use in corrosive environments. For installation, the valve requires a hex size of 1 1/8 inches (28.6 mm) and an installation torque between 45 - 50 lbf\u00b7ft (61 - 68 Nm). The compact unit weighs approximately 0.40 lbs (0.20 kg), facilitating ease of handling and integration into various hydraulic systems without adding significant weight. In summary, the Sun Hydraulics CXFAXCE check valve is engineered for high-pressure applications where fluid control and leakage prevention are paramount, packaged in a design that ensures long-term reliability and performance under challenging conditions.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 40 gpm160 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
