SUN HYDRAULICS
CXFAXDE
$132.34 USD
- SUN HYDRAULICS
- Material:CXFAXDE
- Model:CXFA-XDE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXFAXDE (CXFAXDE) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model is crafted to ensure free flow from the inlet port 1 to the outlet port 2 while blocking reverse flow, making it a critical component in various hydraulic circuits. The CXFAXDE is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports, suitable for high-pressure systems. This valve is distinguished by its exceptionally low leakage rate, less than 1 drop per minute (0.07 cc/min), which promotes system efficiency and reduces fluid loss. It features a T5A cavity and conforms to Series 2 specifications, with a flow capacity up to 40 gpm (160 L/min). The valve's robust construction includes EPDM seals specifically selected for compatibility with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause degradation. Sun Hydraulics has incorporated their floating style construction into the CXFAXDE model to minimize potential internal binding that could result from excessive installation torque or variations in cavity/cartridge machining. This design enhancement contributes to the valve\u2019s reliability and longevity under varying operational conditions. The unit requires an installation torque between 45 \u2013 50 lbf-ft (61 \u2013 68 Nm) and features a hex size of 1-1/8 in. (28.6 mm), facilitating easy installation and maintenance. Weighing just 0.40 lb (0.20 kg), the CXFAXDE combines lightweight design with durable performance, making it an ideal choice for mobile and industrial applications where space and weight are considerations but performance cannot be compromised.
The Sun Hydraulics CXFAXDE (CXFAXDE) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model is crafted to ensure free flow from the inlet port 1 to the outlet port 2 while blocking reverse flow, making it a critical component in various hydraulic circuits. The CXFAXDE is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports, suitable for high-pressure systems. This valve is distinguished by its exceptionally low leakage rate, less than 1 drop per minute (0.07 cc/min), which promotes system efficiency and reduces fluid loss. It features a T5A cavity and conforms to Series 2 specifications, with a flow capacity up to 40 gpm (160 L/min). The valve's robust construction includes EPDM seals specifically selected for compatibility with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause degradation. Sun Hydraulics has incorporated their floating style construction into the CXFAXDE model to minimize potential internal binding that could result from excessive installation torque or variations in cavity/cartridge machining. This design enhancement contributes to the valve\u2019s reliability and longevity under varying operational conditions. The unit requires an installation torque between 45 \u2013 50 lbf-ft (61 \u2013 68 Nm) and features a hex size of 1-1/8 in. (28.6 mm), facilitating easy installation and maintenance. Weighing just 0.40 lb (0.20 kg), the CXFAXDE combines lightweight design with durable performance, making it an ideal choice for mobile and industrial applications where space and weight are considerations but performance cannot be compromised.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 40 gpm160 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
