SUN HYDRAULICS
CXFAXEE
$130.36 USD
- SUN HYDRAULICS
- Material:CXFAXEE
- Model:CXFA-XEE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXFAXEE (CXFAXEE) is a high-performance check valve designed for hydraulic systems. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction. It is particularly notable for its exceptionally low leakage rate, which is less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. The CXFAXEE can handle a maximum operating pressure of 5000 psi (350 bar) at both ports, making it suitable for high-pressure applications. The valve features a T5A cavity and belongs to the Series 2, with a capacity of handling up to 40 gpm (160 L/min). It is engineered with Sun\u2019s floating style construction which helps minimize internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. This design enhances reliability and longevity in demanding operational conditions. For environmental resilience, this model can be configured with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. The cartridge itself is corrosion-resistant, ideal for use in corrosive environments when identified by specific model code suffixes like AP or LH. The CXFAXEE has practical installation dimensions including a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque of between 45 - 50 lbf.ft (61 - 68 Nm). Weighing just 0.40 lb (0.20 kg), it combines lightweight design with robust performance capabilities, making it an essential component for various hydraulic circuit applications where one-way flow is critical.
The Sun Hydraulics CXFAXEE (CXFAXEE) is a high-performance check valve designed for hydraulic systems. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction. It is particularly notable for its exceptionally low leakage rate, which is less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. The CXFAXEE can handle a maximum operating pressure of 5000 psi (350 bar) at both ports, making it suitable for high-pressure applications. The valve features a T5A cavity and belongs to the Series 2, with a capacity of handling up to 40 gpm (160 L/min). It is engineered with Sun\u2019s floating style construction which helps minimize internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. This design enhances reliability and longevity in demanding operational conditions. For environmental resilience, this model can be configured with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. The cartridge itself is corrosion-resistant, ideal for use in corrosive environments when identified by specific model code suffixes like AP or LH. The CXFAXEE has practical installation dimensions including a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque of between 45 - 50 lbf.ft (61 - 68 Nm). Weighing just 0.40 lb (0.20 kg), it combines lightweight design with robust performance capabilities, making it an essential component for various hydraulic circuit applications where one-way flow is critical.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 40 gpm160 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
