SUN HYDRAULICS
CXFCXAV
$55.89 USD
- SUN HYDRAULICS
- Material:CXFCXAV
- Model:CXFC-XAV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXFCXAV (CXFCXAV) is a specialized hydraulic check valve designed for high-efficiency fluid control in various hydraulic systems. This model stands out due to its unique free flow, nose-to-side cheater check valve functionality, which allows it to operate as a standard 2-port check valve in a 3-port cavity configuration, with the third port of the cartridge blocked off. This versatility makes it particularly useful for applications requiring a check valve in an existing three-port cavity. The CXFCXAV is engineered to handle a high capacity of up to 40 gpm (160 L/min) and can withstand maximum operating pressures up to 5000 psi (350 bar). It features extremely low leakage rates, maintaining less than one drop per minute (0.07 cc/min), which ensures efficient and reliable operation even under stringent conditions. The valve's dimensions include a hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm). Further enhancing its performance, the CXFCXAV incorporates Sun Hydraulics' floating style construction. This design minimizes the potential for internal parts binding that can occur due to excessive installation torque or variations in cavity/cartridge machining, thereby ensuring consistent and dependable operation across various applications. The use of Viton seals in its construction also aids in maintaining durability and resistance against harsh fluids and environments. This model is housed within a T2A cavity and belongs to the Series 2 line of Sun Hydraulics' valves.
The Sun Hydraulics CXFCXAV (CXFCXAV) is a specialized hydraulic check valve designed for high-efficiency fluid control in various hydraulic systems. This model stands out due to its unique free flow, nose-to-side cheater check valve functionality, which allows it to operate as a standard 2-port check valve in a 3-port cavity configuration, with the third port of the cartridge blocked off. This versatility makes it particularly useful for applications requiring a check valve in an existing three-port cavity. The CXFCXAV is engineered to handle a high capacity of up to 40 gpm (160 L/min) and can withstand maximum operating pressures up to 5000 psi (350 bar). It features extremely low leakage rates, maintaining less than one drop per minute (0.07 cc/min), which ensures efficient and reliable operation even under stringent conditions. The valve's dimensions include a hex size of 1-1/8 inches (28.6 mm) and an installation torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm). Further enhancing its performance, the CXFCXAV incorporates Sun Hydraulics' floating style construction. This design minimizes the potential for internal parts binding that can occur due to excessive installation torque or variations in cavity/cartridge machining, thereby ensuring consistent and dependable operation across various applications. The use of Viton seals in its construction also aids in maintaining durability and resistance against harsh fluids and environments. This model is housed within a T2A cavity and belongs to the Series 2 line of Sun Hydraulics' valves.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 40 gpm160 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-202-006 |
