SUN HYDRAULICS
CXGBLAN
$167.98 USD
- SUN HYDRAULICS
- Material:CXGBLAN
- Model:CXGB-LAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBLAN (CXGBLAN) is a precision-engineered check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a unique side-to-nose flow path from port 2 to port 1, which is essential for applications where manifold drillings may be incorrect, thus acting as a circuit saver. The valve is characterized by its robust construction with a Delrin seat that makes it suitable for medium pressure systems that encounter dirty conditions but not high flow or temperatures. The CXGBLAN offers an impressive maximum flow capacity of 60 gpm (240 L/min) and can withstand a maximum operating pressure of 3000 psi (210 bar), making it versatile for various hydraulic applications. It is designed to minimize leakage, maintaining tight control with less than 1 drop per minute (0.07 cc/min) leakage, ensuring efficiency and reducing waste in hydraulic systems. This model also incorporates Sun's floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This feature enhances the reliability and longevity of the valve under different installation conditions. The valve has specific installation requirements with a hex size of 1-1/4 inches (31.8 mm) and an installation torque range of 150-160 lbf.ft (203-217 Nm). The unit itself weighs approximately 1.60 lbs (0.70 kg), making it relatively lightweight yet sturdy enough for demanding applications. Overall, the Sun Hydraulics CXGBLAN check valve is an excellent choice for hydraulic circuits needing precise backflow prevention and operational reliability under medium pressure conditions.
The Sun Hydraulics CXGBLAN (CXGBLAN) is a precision-engineered check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a unique side-to-nose flow path from port 2 to port 1, which is essential for applications where manifold drillings may be incorrect, thus acting as a circuit saver. The valve is characterized by its robust construction with a Delrin seat that makes it suitable for medium pressure systems that encounter dirty conditions but not high flow or temperatures. The CXGBLAN offers an impressive maximum flow capacity of 60 gpm (240 L/min) and can withstand a maximum operating pressure of 3000 psi (210 bar), making it versatile for various hydraulic applications. It is designed to minimize leakage, maintaining tight control with less than 1 drop per minute (0.07 cc/min) leakage, ensuring efficiency and reducing waste in hydraulic systems. This model also incorporates Sun's floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This feature enhances the reliability and longevity of the valve under different installation conditions. The valve has specific installation requirements with a hex size of 1-1/4 inches (31.8 mm) and an installation torque range of 150-160 lbf.ft (203-217 Nm). The unit itself weighs approximately 1.60 lbs (0.70 kg), making it relatively lightweight yet sturdy enough for demanding applications. Overall, the Sun Hydraulics CXGBLAN check valve is an excellent choice for hydraulic circuits needing precise backflow prevention and operational reliability under medium pressure conditions.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
