SUN HYDRAULICS
CXGBLBN
$166.99 USD
- SUN HYDRAULICS
- Material:CXGBLBN
- Model:CXGB-LBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBLBN (CXGBLBN) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model features a robust construction that incorporates Sun's floating style to minimize internal part binding due to installation torque or cavity/cartridge machining variations. The valve is housed in a T16A cavity and belongs to the Series 3 lineup, ensuring compatibility with standardized components. With a maximum operating pressure of 3000 psi (210 bar) and a flow capacity of up to 60 gpm (240 L/min), the CXGBLBN is suited for medium pressure systems that are subject to dirt and not exposed to high flow rates or temperatures. The Delrin seat enhances its suitability for dirty environments by providing resistance against contaminants that might otherwise compromise valve integrity. Notably, the valve offers exceptionally low leakage rates, with maximum leakage constrained to less than one drop per minute (0.07 cc/min), making it an ideal choice for applications demanding high sealing efficiency. For ease of installation, the valve comes with a hex size of 1 1/4 inches (31.8 mm) and requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm). It weighs approximately 1.60 lbs (0.70 kg), allowing for manageable handling and integration into existing systems. This model also supports Viton seals through the seal kit/cartridge number 990016006, further enhancing its operational reliability and longevity in challenging conditions. Overall, the Sun Hydraulics CXGBLBN check valve serves as an effective solution for circuit protection in hydraulic systems where incorrect manifold drillings might occur, offering both performance reliability and ease of maintenance.
The Sun Hydraulics CXGBLBN (CXGBLBN) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model features a robust construction that incorporates Sun's floating style to minimize internal part binding due to installation torque or cavity/cartridge machining variations. The valve is housed in a T16A cavity and belongs to the Series 3 lineup, ensuring compatibility with standardized components. With a maximum operating pressure of 3000 psi (210 bar) and a flow capacity of up to 60 gpm (240 L/min), the CXGBLBN is suited for medium pressure systems that are subject to dirt and not exposed to high flow rates or temperatures. The Delrin seat enhances its suitability for dirty environments by providing resistance against contaminants that might otherwise compromise valve integrity. Notably, the valve offers exceptionally low leakage rates, with maximum leakage constrained to less than one drop per minute (0.07 cc/min), making it an ideal choice for applications demanding high sealing efficiency. For ease of installation, the valve comes with a hex size of 1 1/4 inches (31.8 mm) and requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm). It weighs approximately 1.60 lbs (0.70 kg), allowing for manageable handling and integration into existing systems. This model also supports Viton seals through the seal kit/cartridge number 990016006, further enhancing its operational reliability and longevity in challenging conditions. Overall, the Sun Hydraulics CXGBLBN check valve serves as an effective solution for circuit protection in hydraulic systems where incorrect manifold drillings might occur, offering both performance reliability and ease of maintenance.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
