SUN HYDRAULICS
CXGBLCN
$165.00 USD
- SUN HYDRAULICS
- Material:CXGBLCN
- Model:CXGB-LCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBLCN (CXGBLCN) is a specialized hydraulic check valve designed for medium pressure systems where contamination might be an issue. This valve features a unique free flow from sidetonose, allowing fluid to move seamlessly from inlet port 2 to outlet port 1 while preventing backflow in the opposite direction. The Delrin seat incorporated within the CXGBLCN makes it particularly suitable for systems that may encounter dirty conditions but do not experience high flow rates or temperatures. This model benefits from Sun Hydraulics' floating style construction, which minimizes the risk of internal parts binding\u2014a common issue stemming from over-torquing during installation or variations in cavity/cartridge machining. With a maximum operational pressure of 3000 psi (210 bar) and a flow capacity of up to 60 gpm (240 L/min), the CXGBLCN is robust enough for various applications while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min). The valve's compact design, with a hex size of 1-1/4 inches (31.8 mm) and an installation torque range between 150-160 lbf.ft (203-217 Nm), ensures it can be integrated into existing circuits even where manifold drillings are not ideally positioned. This makes it an invaluable circuit saver for correcting such discrepancies without needing extensive modifications. Weighing only 1.60 lbs (0.70 kg), the CXGBLCN also supports easy handling and installation, further complemented by its compatibility with Viton seal kits for enhanced durability and performance under various operational conditions.
The Sun Hydraulics CXGBLCN (CXGBLCN) is a specialized hydraulic check valve designed for medium pressure systems where contamination might be an issue. This valve features a unique free flow from sidetonose, allowing fluid to move seamlessly from inlet port 2 to outlet port 1 while preventing backflow in the opposite direction. The Delrin seat incorporated within the CXGBLCN makes it particularly suitable for systems that may encounter dirty conditions but do not experience high flow rates or temperatures. This model benefits from Sun Hydraulics' floating style construction, which minimizes the risk of internal parts binding\u2014a common issue stemming from over-torquing during installation or variations in cavity/cartridge machining. With a maximum operational pressure of 3000 psi (210 bar) and a flow capacity of up to 60 gpm (240 L/min), the CXGBLCN is robust enough for various applications while maintaining an extremely low leakage rate of less than one drop per minute (0.07 cc/min). The valve's compact design, with a hex size of 1-1/4 inches (31.8 mm) and an installation torque range between 150-160 lbf.ft (203-217 Nm), ensures it can be integrated into existing circuits even where manifold drillings are not ideally positioned. This makes it an invaluable circuit saver for correcting such discrepancies without needing extensive modifications. Weighing only 1.60 lbs (0.70 kg), the CXGBLCN also supports easy handling and installation, further complemented by its compatibility with Viton seal kits for enhanced durability and performance under various operational conditions.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
