SUN HYDRAULICS
CXGBLCV
$171.45 USD
- SUN HYDRAULICS
- Material:CXGBLCV
- Model:CXGB-LCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBLCV (CXGBLCV) is a robust check valve designed for medium-pressure hydraulic systems. This model features a free flow from inlet port 2 to outlet port 1, effectively blocking flow in the reverse direction, which makes it an ideal choice for applications requiring one-way flow control. The valve is equipped with a Delrin seat, enhancing its suitability for systems that handle dirty environments but are not exposed to high flows or extreme temperatures. The CXGBLCV model operates efficiently with a maximum operating pressure of 3000 psi (210 bar) and has a flow capacity of up to 60 gpm (240 L/min). It is specifically crafted to minimize leakage, boasting an impressively low maximum leakage rate of less than 1 drop per minute (0.07 cc/min). This attribute, combined with Sun's floating style construction, ensures reduced risk of internal parts binding which can arise from excessive installation torque or variations in cavity/cartridge machining. With a compact design weighing only 1.60 lbs (0.70 kg), the CXGBLCV incorporates a T16A cavity and is part of the Series 3 lineup from Sun Hydraulics. The valve\u2019s hex size is 1 \u00bc inches (31.8 mm), and it requires an installation torque between 150 and 160 lbf-ft (203 \u2013 217 Nm). These specifications make the CXGBLCV not only effective but also versatile for various hydraulic circuit applications where incorrect manifold drillings need correction without compromising system integrity.
The Sun Hydraulics CXGBLCV (CXGBLCV) is a robust check valve designed for medium-pressure hydraulic systems. This model features a free flow from inlet port 2 to outlet port 1, effectively blocking flow in the reverse direction, which makes it an ideal choice for applications requiring one-way flow control. The valve is equipped with a Delrin seat, enhancing its suitability for systems that handle dirty environments but are not exposed to high flows or extreme temperatures. The CXGBLCV model operates efficiently with a maximum operating pressure of 3000 psi (210 bar) and has a flow capacity of up to 60 gpm (240 L/min). It is specifically crafted to minimize leakage, boasting an impressively low maximum leakage rate of less than 1 drop per minute (0.07 cc/min). This attribute, combined with Sun's floating style construction, ensures reduced risk of internal parts binding which can arise from excessive installation torque or variations in cavity/cartridge machining. With a compact design weighing only 1.60 lbs (0.70 kg), the CXGBLCV incorporates a T16A cavity and is part of the Series 3 lineup from Sun Hydraulics. The valve\u2019s hex size is 1 \u00bc inches (31.8 mm), and it requires an installation torque between 150 and 160 lbf-ft (203 \u2013 217 Nm). These specifications make the CXGBLCV not only effective but also versatile for various hydraulic circuit applications where incorrect manifold drillings need correction without compromising system integrity.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
