SUN HYDRAULICS
CXGBLFN
$166.99 USD
- SUN HYDRAULICS
- Material:CXGBLFN
- Model:CXGB-LFN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBLFN (CXGBLFN) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model features a freeflow, side-to-nose configuration that allows free flow from inlet port 2 to outlet port 1 and blocks flow in the opposite direction. The Delrin seat incorporated in the CXGBLFN makes it suitable for medium pressure systems that may contain some degree of contamination but do not experience high flows or temperatures. This two-port check valve is specifically engineered to fit the same cavity (T16A) across a given frame size, although attention must be paid to the direction of flow paths which can be opposite. It offers a solution as a circuit saver especially in scenarios where existing manifold drillings are incorrect, allowing for corrections without extensive system modifications. The valve's capacity is noted to be around 30% less than models with a nose-to-side flow path, but it still supports up to 60 gpm (240 L/min). One of the standout features of the CXGBLFN is its extremely low leakage rate\u2014less than one drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss even under maximum operating pressures of up to 3000 psi (210 bar). The construction benefits from Sun\u2019s floating style design which minimizes internal parts binding due to variations in installation torque or cavity/cartridge machining. The valve requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm) and has a hex size of 1-1/4 inches (31.8 mm). Weighing just about 1.60 lb (0.70 kg), this model demonstrates both robustness and reliability in various hydraulic applications while maintaining ease of maintenance with available Viton seal kits and cartridges.
The Sun Hydraulics CXGBLFN (CXGBLFN) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model features a freeflow, side-to-nose configuration that allows free flow from inlet port 2 to outlet port 1 and blocks flow in the opposite direction. The Delrin seat incorporated in the CXGBLFN makes it suitable for medium pressure systems that may contain some degree of contamination but do not experience high flows or temperatures. This two-port check valve is specifically engineered to fit the same cavity (T16A) across a given frame size, although attention must be paid to the direction of flow paths which can be opposite. It offers a solution as a circuit saver especially in scenarios where existing manifold drillings are incorrect, allowing for corrections without extensive system modifications. The valve's capacity is noted to be around 30% less than models with a nose-to-side flow path, but it still supports up to 60 gpm (240 L/min). One of the standout features of the CXGBLFN is its extremely low leakage rate\u2014less than one drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss even under maximum operating pressures of up to 3000 psi (210 bar). The construction benefits from Sun\u2019s floating style design which minimizes internal parts binding due to variations in installation torque or cavity/cartridge machining. The valve requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm) and has a hex size of 1-1/4 inches (31.8 mm). Weighing just about 1.60 lb (0.70 kg), this model demonstrates both robustness and reliability in various hydraulic applications while maintaining ease of maintenance with available Viton seal kits and cartridges.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
