SUN HYDRAULICS
CXGBLZN
$168.97 USD
- SUN HYDRAULICS
- Material:CXGBLZN
- Model:CXGB-LZN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBLZN (CXGBLZN) is a highly efficient and robust check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model features a freeflow, side-to-nose check valve configuration that allows free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction. The Delrin seat within the valve makes it particularly suitable for medium pressure systems that may contain some level of contamination but do not experience high flow rates or temperatures. The CXGBLZN check valve is engineered to fit into a T16A cavity and belongs to Series 3. It boasts a maximum operating capacity of 60 gpm (240 L/min) and can handle pressures up to 3000 psi (210 bar). One of its standout features is its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. This model's construction incorporates Sun Hydraulics' floating style design, which minimizes the risk of internal parts binding\u2014a common issue that can arise from over-torquing during installation or variances in cavity/cartridge machining. The valve requires an installation torque between 150 - 160 lbf\u00b7ft (203 - 217 Nm) and has a hex size of 1-1/4 inches (31.8 mm). Weighing only 1.60 lbs (0.70 kg), it offers a compact yet powerful solution for enhancing circuit performance, especially in existing setups where manifold drillings may be incorrect. Overall, the Sun Hydraulics CXGBLZN check valve is an excellent choice for applications requiring reliable check functionality with minimal leakage and operational disruptions due to its advanced design features and robust construction.
The Sun Hydraulics CXGBLZN (CXGBLZN) is a highly efficient and robust check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model features a freeflow, side-to-nose check valve configuration that allows free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction. The Delrin seat within the valve makes it particularly suitable for medium pressure systems that may contain some level of contamination but do not experience high flow rates or temperatures. The CXGBLZN check valve is engineered to fit into a T16A cavity and belongs to Series 3. It boasts a maximum operating capacity of 60 gpm (240 L/min) and can handle pressures up to 3000 psi (210 bar). One of its standout features is its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. This model's construction incorporates Sun Hydraulics' floating style design, which minimizes the risk of internal parts binding\u2014a common issue that can arise from over-torquing during installation or variances in cavity/cartridge machining. The valve requires an installation torque between 150 - 160 lbf\u00b7ft (203 - 217 Nm) and has a hex size of 1-1/4 inches (31.8 mm). Weighing only 1.60 lbs (0.70 kg), it offers a compact yet powerful solution for enhancing circuit performance, especially in existing setups where manifold drillings may be incorrect. Overall, the Sun Hydraulics CXGBLZN check valve is an excellent choice for applications requiring reliable check functionality with minimal leakage and operational disruptions due to its advanced design features and robust construction.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
