SUN HYDRAULICS
CXGBLZV
$175.43 USD
- SUN HYDRAULICS
- Material:CXGBLZV
- Model:CXGB-LZV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBLZV (CXGBLZV) is a highly efficient and reliable hydraulic check valve designed for medium pressure systems. This model features a Delrin seat, making it particularly suitable for applications with dirty conditions where there may not be high flow or extreme temperatures. The CXGBLZV is a two-port check valve that allows free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction, providing essential protection and functionality in hydraulic circuits. This model is built to accommodate the same cavity size (T16A) across similar frame sizes but requires careful attention to the direction of flow paths which may be opposite. With a maximum operating pressure of 3000 psi (210 bar) and a capacity of 60 gpm (240 L/min), it meets rigorous operational demands. The valve's design incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. One of its standout features is its exceptionally low leakage rate, with maximum leakage limited to less than one drop per minute (0.07 cc/min). This precision ensures minimal fluid loss, contributing to the overall efficiency and cleanliness of the hydraulic system. The CXGBLZV also supports easy maintenance and replacement with available Viton seal kits and cartridges. Overall, the Sun Hydraulics CXGBLZV check valve is an ideal solution for existing circuits needing circuit correction or protection against incorrect manifold drillings, providing reliability without compromising on performance.
The Sun Hydraulics CXGBLZV (CXGBLZV) is a highly efficient and reliable hydraulic check valve designed for medium pressure systems. This model features a Delrin seat, making it particularly suitable for applications with dirty conditions where there may not be high flow or extreme temperatures. The CXGBLZV is a two-port check valve that allows free flow from the inlet port 2 to the outlet port 1 while blocking flow in the opposite direction, providing essential protection and functionality in hydraulic circuits. This model is built to accommodate the same cavity size (T16A) across similar frame sizes but requires careful attention to the direction of flow paths which may be opposite. With a maximum operating pressure of 3000 psi (210 bar) and a capacity of 60 gpm (240 L/min), it meets rigorous operational demands. The valve's design incorporates Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. One of its standout features is its exceptionally low leakage rate, with maximum leakage limited to less than one drop per minute (0.07 cc/min). This precision ensures minimal fluid loss, contributing to the overall efficiency and cleanliness of the hydraulic system. The CXGBLZV also supports easy maintenance and replacement with available Viton seal kits and cartridges. Overall, the Sun Hydraulics CXGBLZV check valve is an ideal solution for existing circuits needing circuit correction or protection against incorrect manifold drillings, providing reliability without compromising on performance.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
