SUN HYDRAULICS
CXGBXBV
$165.50 USD
- SUN HYDRAULICS
- Material:CXGBXBV
- Model:CXGB-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBXBV (CXGBXBV) is a high-performance hydraulic check valve designed for efficient operation in medium pressure systems. This model features a unique free flow from its inlet port (port 2) to the outlet port (port 1), while effectively blocking flow in the reverse direction, making it an essential component for directional control in hydraulic circuits. The valve is constructed with a Delrin seat, which provides durability and reliability even in environments with dirty fluids, though it is not intended for high flow or high temperature applications. The CXGBXBV can be used interchangeably within the same cavity for different frame sizes, but attention must be paid to the direction of flow paths which may vary. This versatility makes it particularly useful as a circuit saver in systems where manifold drillings might have been incorrectly executed. One of the standout features of this model is its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. This valve supports a maximum operating pressure of 3000 psi (210 bar) and has a flow capacity up to 60 gpm (240 L/min). It incorporates Sun\u2019s floating style construction, which reduces risks associated with internal parts binding due to excessive installation torque or machining variations. For installation, the valve requires a torque between 150-160 lbf ft (203-217 Nm) and comes equipped with Viton seals for enhanced performance under varying conditions. Weighing at approximately 1.60 lb (0.70 kg), the CXGBXBV combines robust construction with reliable operation, making it suitable for a wide range of hydraulic applications where precision and durability are paramount.
The Sun Hydraulics CXGBXBV (CXGBXBV) is a high-performance hydraulic check valve designed for efficient operation in medium pressure systems. This model features a unique free flow from its inlet port (port 2) to the outlet port (port 1), while effectively blocking flow in the reverse direction, making it an essential component for directional control in hydraulic circuits. The valve is constructed with a Delrin seat, which provides durability and reliability even in environments with dirty fluids, though it is not intended for high flow or high temperature applications. The CXGBXBV can be used interchangeably within the same cavity for different frame sizes, but attention must be paid to the direction of flow paths which may vary. This versatility makes it particularly useful as a circuit saver in systems where manifold drillings might have been incorrectly executed. One of the standout features of this model is its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. This valve supports a maximum operating pressure of 3000 psi (210 bar) and has a flow capacity up to 60 gpm (240 L/min). It incorporates Sun\u2019s floating style construction, which reduces risks associated with internal parts binding due to excessive installation torque or machining variations. For installation, the valve requires a torque between 150-160 lbf ft (203-217 Nm) and comes equipped with Viton seals for enhanced performance under varying conditions. Weighing at approximately 1.60 lb (0.70 kg), the CXGBXBV combines robust construction with reliable operation, making it suitable for a wide range of hydraulic applications where precision and durability are paramount.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
