SUN HYDRAULICS
CXGBXEV
$163.51 USD
- SUN HYDRAULICS
- Material:CXGBXEV
- Model:CXGB-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBXEV (CXGBXEV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a free-flow design allowing fluid to travel freely from the inlet port 2 to the outlet port 1 while blocking reverse flow, making it an ideal choice for systems where flow directionality is crucial. The CXGBXEV utilizes a Delrin seat which provides durability and compatibility with medium pressure systems that may contain some degree of contamination without compromising performance. This two-port check valve fits within a T16A cavity and adheres to Series 3 specifications. It can handle a maximum capacity of 60 gallons per minute (240 L/min) and withstand pressures up to 3000 psi (210 bar). The precision-engineered valve ensures extremely low leakage rates, not exceeding 1 drop per minute (0.07 cc/min), which is critical for maintaining system efficiency and preventing fluid loss. The valve's hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm). Weighing only 1.60 lbs (0.70 kg), the CXGBXEV incorporates Sun's floating style construction, which reduces the risk of internal parts binding due to variations in installation torque or machining discrepancies in the cavity or cartridge. Additionally, this model can be equipped with a Viton seal kit/cartridge, enhancing its operational reliability under varying environmental conditions. The CXGBXEV is particularly useful as a circuit saver in applications where manifold drillings might be incorrect, providing flexibility and retrofitting options without extensive system modifications.
The Sun Hydraulics CXGBXEV (CXGBXEV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a free-flow design allowing fluid to travel freely from the inlet port 2 to the outlet port 1 while blocking reverse flow, making it an ideal choice for systems where flow directionality is crucial. The CXGBXEV utilizes a Delrin seat which provides durability and compatibility with medium pressure systems that may contain some degree of contamination without compromising performance. This two-port check valve fits within a T16A cavity and adheres to Series 3 specifications. It can handle a maximum capacity of 60 gallons per minute (240 L/min) and withstand pressures up to 3000 psi (210 bar). The precision-engineered valve ensures extremely low leakage rates, not exceeding 1 drop per minute (0.07 cc/min), which is critical for maintaining system efficiency and preventing fluid loss. The valve's hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm). Weighing only 1.60 lbs (0.70 kg), the CXGBXEV incorporates Sun's floating style construction, which reduces the risk of internal parts binding due to variations in installation torque or machining discrepancies in the cavity or cartridge. Additionally, this model can be equipped with a Viton seal kit/cartridge, enhancing its operational reliability under varying environmental conditions. The CXGBXEV is particularly useful as a circuit saver in applications where manifold drillings might be incorrect, providing flexibility and retrofitting options without extensive system modifications.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
