SUN HYDRAULICS
CXHAXBE
$193.00 USD
- SUN HYDRAULICS
- Material:CXHAXBE
- Model:CXHA-XBE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHAXBE (CXHAXBE) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring operational efficiency and safety. The CXHAXBE model is distinguished by its extremely low leakage rate, with a maximum of less than one drop per minute (0.07 cc/min), making it ideal for systems where minimal fluid loss is critical. Constructed to handle a maximum operating pressure of 5000 psi (350 bar) at both ports, this valve can accommodate flows up to 80 gpm (320 L/min). It features a T16A cavity and belongs to Series 3, indicating its compatibility with specific hydraulic setups. The valve's robust design includes Sun's floating style construction that minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. For environments involving corrosive substances, cartridges configured with EPDM seals are recommended specifically for use with phosphate ester fluids; however, these should not be exposed to petroleum-based fluids as they can degrade the seals. The CXHAXBE model weighs 1.60 lbs (0.70 kg) and requires an installation torque of between 150 - 160 lbf-ft (203 - 217 Nm), ensuring a secure fit and reliable operation in demanding applications.
The Sun Hydraulics CXHAXBE (CXHAXBE) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring operational efficiency and safety. The CXHAXBE model is distinguished by its extremely low leakage rate, with a maximum of less than one drop per minute (0.07 cc/min), making it ideal for systems where minimal fluid loss is critical. Constructed to handle a maximum operating pressure of 5000 psi (350 bar) at both ports, this valve can accommodate flows up to 80 gpm (320 L/min). It features a T16A cavity and belongs to Series 3, indicating its compatibility with specific hydraulic setups. The valve's robust design includes Sun's floating style construction that minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. For environments involving corrosive substances, cartridges configured with EPDM seals are recommended specifically for use with phosphate ester fluids; however, these should not be exposed to petroleum-based fluids as they can degrade the seals. The CXHAXBE model weighs 1.60 lbs (0.70 kg) and requires an installation torque of between 150 - 160 lbf-ft (203 - 217 Nm), ensuring a secure fit and reliable operation in demanding applications.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
