SUN HYDRAULICS
CXHAXGE
$193.00 USD
- SUN HYDRAULICS
- Material:CXHAXGE
- Model:CXHA-XGE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHAXGE (CXHAXGE) is a high-performance check valve designed for hydraulic applications requiring reliable, unidirectional flow control. This model is part of the T16A cavity series and offers a robust capacity of up to 80 gpm (320 L/min), making it suitable for a wide range of fluid dynamics applications. The CXHAXGE can withstand a maximum operating pressure of 5000 psi (350 bar), ensuring it performs under high-pressure conditions. This valve features exceptionally low leakage rates, with maximum leakage constrained to less than one drop per minute (0.07 cc/min), which highlights its efficiency and precision in preventing fluid loss. The valve is constructed using corrosion-resistant materials, making it ideal for use in corrosive environments. Notably, this model uses EPDM seals specifically designed for phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids, greases, and lubricants as they could be damaged. The CXHAXGE incorporates Sun Hydraulics\u2019 floating style construction which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This feature enhances the overall durability and reliability of the valve in demanding operational contexts. The valve's hex size is 1 1/4 in. (31.8 mm) and requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm). Weighing at approximately 1.60 lbs (0.70 kg), this model combines lightweight design with robust performance capabilities, making it an excellent choice for various hydraulic circuit applications where flow needs to be meticulously controlled.
The Sun Hydraulics CXHAXGE (CXHAXGE) is a high-performance check valve designed for hydraulic applications requiring reliable, unidirectional flow control. This model is part of the T16A cavity series and offers a robust capacity of up to 80 gpm (320 L/min), making it suitable for a wide range of fluid dynamics applications. The CXHAXGE can withstand a maximum operating pressure of 5000 psi (350 bar), ensuring it performs under high-pressure conditions. This valve features exceptionally low leakage rates, with maximum leakage constrained to less than one drop per minute (0.07 cc/min), which highlights its efficiency and precision in preventing fluid loss. The valve is constructed using corrosion-resistant materials, making it ideal for use in corrosive environments. Notably, this model uses EPDM seals specifically designed for phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids, greases, and lubricants as they could be damaged. The CXHAXGE incorporates Sun Hydraulics\u2019 floating style construction which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This feature enhances the overall durability and reliability of the valve in demanding operational contexts. The valve's hex size is 1 1/4 in. (31.8 mm) and requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm). Weighing at approximately 1.60 lbs (0.70 kg), this model combines lightweight design with robust performance capabilities, making it an excellent choice for various hydraulic circuit applications where flow needs to be meticulously controlled.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
