SUN HYDRAULICS
CXHAXZE
$194.99 USD
- SUN HYDRAULICS
- Material:CXHAXZE
- Model:CXHA-XZE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHAXZE (CXHAXZE) is a high-performance, two-port check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a robust construction that supports free flow from the inlet (port 1) to the outlet (port 2) while preventing reverse flow, ensuring operational integrity and system safety. The CXHAXZE valve is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports, making it suitable for high-pressure applications. With a maximum capacity of 80 gpm (320 L/min), the CXHAXZE is designed to accommodate substantial fluid volumes, enhancing system efficiency. It also boasts an exceptionally low leakage rate of less than one drop per minute (0.07 cc/min), which contributes to maintaining system cleanliness and reducing fluid loss. The valve's hex size is 1-1/4 in (31.8 mm), and it requires an installation torque between 150 \u2013 160 lbf\u00b7ft (203 \u2013 217 Nm), ensuring secure and straightforward installation. The CXHAXZE employs EPDM seals configured specifically for use with phosphate ester fluids; however, these seals are sensitive to petroleum-based fluids, greases, and lubricants which can cause damage. Additionally, the valve incorporates Sun\u2019s floating style construction which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. Weighing at approximately 1.60 lb (0.70 kg), this model combines lightweight design with durable performance for various hydraulic applications.
The Sun Hydraulics CXHAXZE (CXHAXZE) is a high-performance, two-port check valve designed for hydraulic systems requiring reliable, one-way flow control. This model features a robust construction that supports free flow from the inlet (port 1) to the outlet (port 2) while preventing reverse flow, ensuring operational integrity and system safety. The CXHAXZE valve is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports, making it suitable for high-pressure applications. With a maximum capacity of 80 gpm (320 L/min), the CXHAXZE is designed to accommodate substantial fluid volumes, enhancing system efficiency. It also boasts an exceptionally low leakage rate of less than one drop per minute (0.07 cc/min), which contributes to maintaining system cleanliness and reducing fluid loss. The valve's hex size is 1-1/4 in (31.8 mm), and it requires an installation torque between 150 \u2013 160 lbf\u00b7ft (203 \u2013 217 Nm), ensuring secure and straightforward installation. The CXHAXZE employs EPDM seals configured specifically for use with phosphate ester fluids; however, these seals are sensitive to petroleum-based fluids, greases, and lubricants which can cause damage. Additionally, the valve incorporates Sun\u2019s floating style construction which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. Weighing at approximately 1.60 lb (0.70 kg), this model combines lightweight design with durable performance for various hydraulic applications.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
