SUN HYDRAULICS
CXHCXAN
$92.03 USD
- SUN HYDRAULICS
- Material:CXHCXAN
- Model:CXHC-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHCXAN (CXHCXAN) is a versatile check valve designed for hydraulic systems requiring reliable, low-leakage one-way flow control in a three-port cavity configuration. This model utilizes a unique freeflow, nose-to-side cheater design that allows it to function effectively as a standard 2-port check valve while the third port of the cartridge is blocked off. This feature makes it particularly useful for applications where a check valve integration is needed without altering existing three-port cavity setups. The CXHCXAN boasts an impressive maximum flow capacity of 80 gpm (320 L/min) and can withstand operating pressures up to 5000 psi (350 bar), ensuring robust performance in demanding conditions. It is engineered with Sun Hydraulics' floating style construction which helps prevent internal parts from binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. Additionally, this model offers exceptionally low leakage rates, with maximum leakage not exceeding 1 drop per minute (0.07 cc/min), contributing to enhanced system efficiency and reliability. The valve's hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150-160 lbf-ft (203-217 Nm). For maintenance or repair, Viton seal kits are available under part number 990017006. Ideal for various hydraulic applications that demand precise fluid control and minimal leakage, the CXHCXAN check valve provides an effective solution for enhancing circuit functionality within existing three-port setups without necessitating extensive modifications.
The Sun Hydraulics CXHCXAN (CXHCXAN) is a versatile check valve designed for hydraulic systems requiring reliable, low-leakage one-way flow control in a three-port cavity configuration. This model utilizes a unique freeflow, nose-to-side cheater design that allows it to function effectively as a standard 2-port check valve while the third port of the cartridge is blocked off. This feature makes it particularly useful for applications where a check valve integration is needed without altering existing three-port cavity setups. The CXHCXAN boasts an impressive maximum flow capacity of 80 gpm (320 L/min) and can withstand operating pressures up to 5000 psi (350 bar), ensuring robust performance in demanding conditions. It is engineered with Sun Hydraulics' floating style construction which helps prevent internal parts from binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. Additionally, this model offers exceptionally low leakage rates, with maximum leakage not exceeding 1 drop per minute (0.07 cc/min), contributing to enhanced system efficiency and reliability. The valve's hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150-160 lbf-ft (203-217 Nm). For maintenance or repair, Viton seal kits are available under part number 990017006. Ideal for various hydraulic applications that demand precise fluid control and minimal leakage, the CXHCXAN check valve provides an effective solution for enhancing circuit functionality within existing three-port setups without necessitating extensive modifications.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-17A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-017-006 |
