SUN HYDRAULICS
CXHCXBV
$98.98 USD
- SUN HYDRAULICS
- Material:CXHCXBV
- Model:CXHC-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHCXBV (CXHCXBV) is a specialized hydraulic check valve designed for versatile applications in hydraulic systems. This model stands out due to its unique free-flow, nose-to-side cheater check valve functionality, which operates as a standard 2-port check valve when the third port of the cartridge is blocked off. This feature makes it particularly useful for circuits requiring a check valve in an existing three-port cavity. The CXHCXBV model boasts an impressive flow capacity of up to 80 gpm (320 L/min) and can handle maximum operating pressures up to 5000 psi (350 bar). It ensures extremely low leakage rates, with maximum leakage capped at less than one drop per minute (0.07 cc/min), highlighting its efficiency and reliability in preventing fluid loss. The construction of the CXHCXBV incorporates Sun\u2019s floating style design, which minimizes potential internal part binding that could result from excessive installation torque or variations in cavity/cartridge machining. This valve is housed in a T17A cavity and belongs to Sun Hydraulics' Series 3. It requires specific installation torque ranging between 150 - 160 lbf ft (203 - 217 Nm), and uses a Viton seal kit (part number: 990017006) ensuring durability and resistance against high temperatures and chemical degradation. With a hex size of 1-1/4 inches (31.8 mm), the CXHCXBV provides a robust solution for high-demand hydraulic applications requiring precise fluid control with minimal leakage.
The Sun Hydraulics CXHCXBV (CXHCXBV) is a specialized hydraulic check valve designed for versatile applications in hydraulic systems. This model stands out due to its unique free-flow, nose-to-side cheater check valve functionality, which operates as a standard 2-port check valve when the third port of the cartridge is blocked off. This feature makes it particularly useful for circuits requiring a check valve in an existing three-port cavity. The CXHCXBV model boasts an impressive flow capacity of up to 80 gpm (320 L/min) and can handle maximum operating pressures up to 5000 psi (350 bar). It ensures extremely low leakage rates, with maximum leakage capped at less than one drop per minute (0.07 cc/min), highlighting its efficiency and reliability in preventing fluid loss. The construction of the CXHCXBV incorporates Sun\u2019s floating style design, which minimizes potential internal part binding that could result from excessive installation torque or variations in cavity/cartridge machining. This valve is housed in a T17A cavity and belongs to Sun Hydraulics' Series 3. It requires specific installation torque ranging between 150 - 160 lbf ft (203 - 217 Nm), and uses a Viton seal kit (part number: 990017006) ensuring durability and resistance against high temperatures and chemical degradation. With a hex size of 1-1/4 inches (31.8 mm), the CXHCXBV provides a robust solution for high-demand hydraulic applications requiring precise fluid control with minimal leakage.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-17A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-017-006 |
