SUN HYDRAULICS
CXHCXCV
$97.00 USD
- SUN HYDRAULICS
- Material:CXHCXCV
- Model:CXHC-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHCXCV (CXHCXCV) is a specialized hydraulic component designed for versatile applications requiring reliable check valve functionality within a three-port cavity system. This model is part of the T17A cavity series and falls under the Series 3 classification, demonstrating robust performance with a capacity to handle up to 80 gpm (320 L/min). It is engineered to operate under high pressures, withstanding a maximum of 5000 psi (350 bar), making it suitable for demanding hydraulic systems. One of the key features of this check valve is its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), ensuring efficient and clean operation. The CXHCXCV utilizes Sun\u2019s floating style construction, which significantly reduces the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. For installation, this valve requires a hex size of 1 1/4 in (31.8 mm) and an installation torque between 150 - 160 lbf\u00b7ft (203 - 217 Nm). It also supports Viton seals, as indicated by the seal kit/cartridge specification Viton: 990017006, enhancing its durability and performance in various operating environments. Overall, the Sun Hydraulics CXHCXCV check valve offers a reliable solution for integrating into existing three-port cavities where standard two-port check valves are insufficient, providing flexibility and reliability in hydraulic circuit design.
The Sun Hydraulics CXHCXCV (CXHCXCV) is a specialized hydraulic component designed for versatile applications requiring reliable check valve functionality within a three-port cavity system. This model is part of the T17A cavity series and falls under the Series 3 classification, demonstrating robust performance with a capacity to handle up to 80 gpm (320 L/min). It is engineered to operate under high pressures, withstanding a maximum of 5000 psi (350 bar), making it suitable for demanding hydraulic systems. One of the key features of this check valve is its extremely low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), ensuring efficient and clean operation. The CXHCXCV utilizes Sun\u2019s floating style construction, which significantly reduces the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. For installation, this valve requires a hex size of 1 1/4 in (31.8 mm) and an installation torque between 150 - 160 lbf\u00b7ft (203 - 217 Nm). It also supports Viton seals, as indicated by the seal kit/cartridge specification Viton: 990017006, enhancing its durability and performance in various operating environments. Overall, the Sun Hydraulics CXHCXCV check valve offers a reliable solution for integrating into existing three-port cavities where standard two-port check valves are insufficient, providing flexibility and reliability in hydraulic circuit design.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-17A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-017-006 |
